U-POE is designed to power 802.3af PoE devices. U-POE-AF delivers up to 15W of PoE that can be used to power U6-Lite-EU and other 802.3af devices, while also protecting against electrical surges (ESD)
-
Brand: UBIQUITI
-
Category: Power Adapter
-
SKU: AS-U-POE-EU
-
EAN: 817882024976
-
Warranty: 12 months
Specifications
| Power Device Type |
Power Adapter |
| Power Device Location |
External |
| Input Voltage |
AC 100-240 V |
| Input Frequency |
50/60 Hz |
| Rated Input Current |
500 mA |
| Input Power Connectors Quantity |
1 |
| Input Power Connectors Type |
IEC-320 C6 |
| Output Voltage |
DC 48 V |
| Maximum Output Power |
15 W |
| Output Power Connectors Quantity |
2 |
| Output Power Connectors Type |
RJ-45 |
| Circuit Protection |
Surge Protection |
| Power Adapter and Power Supply Features |
PoE (802.3af) |
| Built-in Devices |
LED Indicator |
| Efficiency |
84.25% |
| Certifications |
CE, FCC, IC, UL |
| Maximum Operating Ambient Temperature |
40 °C |
| Minimum Operating Ambient Temperature |
0 °C |
| Maximum Non-Operating Ambient Temperature |
70 °C |
| Minimum Non-Operating Ambient Temperature |
-30 °C |
| Maximum Operating Humidity |
95 % |
| Minimum Operating Humidity |
10 % |
| External Color |
White |
| Included Accessories |
Quick Start Guide |
| Depth (mm) |
46 mm |
| Height (mm) |
86 mm |
| Width (mm) |
33 mm |
| Nominal Weight |
100 g |
| Warranty Products Returnable |
Yes |
| Warranty Term (month) |
12 month(s) |
| Warranty Validation Criteria |
Serial Number |
| Warranty Term Notes |
24 months - for EU |
| Pack Length (mm) |
200 mm |
| Pack Width (mm) |
80 mm |
| Pack Height (mm) |
40 mm |
| Pack Weight Brutto (kg) |
0.2332 kg |
| Pack Weight Netto (kg) |
0.18 kg |
| Pieces in pack |
1 |
| Box Length (mm) |
500 mm |
| Box Width (mm) |
290 mm |
| Box Height (mm) |
390 mm |
| Retail Packaging Net Weight Plastic |
0.24 kg |
| Packs in Box |
50 |
| Package Type |
Box |
| EAN Code |
817882024976 |
