TP-LINK OMADA BE9300 TRI-BAND WIFI7 OUTDOOR AP

Features

• BE9300 Tri-Band Wi-Fi 7 (5765Mbps on 6GHz + 2882Mbps on 5GHz + 688Mbps on 2.4GHz)
• A clear 6GHz band brings cleaner and wider band resources
• 1× 2.5G Port unlocks the full potential of Wi-Fi 7
• 320MHz bandwidth enables many more simultaneous transmissions
• Multi-Link Operation and Multi-RUs ensure the high performance of your network
• Advanced Functions: Centralized management, mesh, and AI roaming

Specifications

Hardware Features

• Interface: 1× 2.5G Ethernet Port
• Button: Reset
• Power Supply: 802.3at PoE or 12V/2.5A DC
• Max. Power Consumption:
• 24.05 W (For PoE);
• 20.92 W (For DC)
• Dimensions ( W x D x H ): 220 × 220 × 32.5mm
• Antenna:
• 2.4 GHz: 2× 4.0 dBi
• 5 GHz: 2× 5.0 dBi
• 6 GHz: 2× 5.0 dBi
• Bluetooth: 1 × 4.0 dBi, Bluetooth 5.2
• Mounting: Ceiling / Wall Mounting (Kits Included)

Wireless Features

• Coverage: 140m²
• Concurrent Clients: 380
• Wireless Standards: IEEE 802.11 a/b/g/n/ac/ax/be
• Frequency: 6GHz, 5GHz, and 2.4GHz
• Signal Rate: 688Mbps (2.4GHz) + 2882Mbps (5GHz) + 5765Mbps (6GHz)

Wireless Functions

• MLO
• 4K-QAM
• Seamless Roaming (802.11k/v/r)
• MU-MIMO
• EHT320
• Mesh
• BSS Coloring
• OFDMA
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS: 24 (8 on each band)
• Wireless Schedule
• Reboot Schedule
• QoS (WMM)
• Rate Limit
• Static IP/Dynamic IP
• RADIUS Accounting
• MAC Authentication

Wireless Security:

• Captive Portal Authentication
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
• Transmission Power:
• < 20 dBm (2.4 GHz, EIRP)
• < 23 dBm (5 GHz, band 1&band 2, EIRP)
• < 28 dBm (5 GHz, band 3, EIRP)
• < 23dBm (6 GHz, EIRP)

Management Features

• Omada App: Yes
• Centralized Management:
• Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Cloud Access: Yes. Require the use of an OC300, OC200, Omada Software Controller or an Omada Cloud-Based Controller
• Email Alerts: Yes
• LED ON/OFF Control: Yes
• Management MAC Access Control: Yes
• SNMP: v1, v2c, v3
• System Logging Local/Remote Syslog: Yes
• Web-based Management: Yes

Others

• Certification: CE, FCC, RoHS, IC
• Environment:
• Operating Temperature: 0°C–40°C;
• Storage Temperature: -40°C–70°C;
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing;

Note: Power Adapter is NOT included

Shipping Dimensions

• Length: 32.4 cm
• Width: 24.5 cm
• Height: 10.4 cm
• Weight: 1.99 kg
