Features
- BE5000 Dual-Band Wi-Fi 7 (4,324Mbps on 5.0GHz plus 688Mbps on 2.4GHz)
- 1× 2.5GbE port unlocks the full potential of Wi-Fi 7
- 240MHz bandwidth enables many more simultaneous transmissions
- Multi-Link Operation and Multi-RUs ensure the high-performance of your network
- Advanced functions – centralised management, mesh and seamless roaming
Specifications
Hardware Features
- Interface: 1× 2.5G Ethernet Port
- Button: Reset
- Power Supply: 802.3at PoE or 12V 1.5A DC (Power Adapter is Not Included)
- Max. Power Consumption:
- 17.8W (PoE)
- 14W (Dc)
- Dimensions (W × D × H): 160 × 160 × 36.7mm
- Antenna:
- 2.4GHz: 2× 4dBi
- 5.0GHz: 2× 5dBi
- Mounting: Ceiling / Wall-Mounting / Junction Box (Kits Included)
Wireless Features
- Coverage: 140m²
- Concurrent Clients: 250+
- Wireless Standards: IEEE 802.11 a/b/g/n/ac/ax/be
- Frequency: 2.4GHz and 5.0GHz
- Signal Rate: 688Mbps (2.4GHz) + 4,324Mbps (5.0GHz)
Wireless Functions
- MLO
- 4K-QAM
- Seamless Roaming
- MU-MIMO
- EHT240
- Mesh
- OFDMA
- Load Balance
- Band Steering
- Beamforming
- Airtime Fairness
- Multiple SSIDS: 16× (8× on each Band)
- Wireless Schedule
- Reboot Schedule
- QoS (WMM)
- Rate Limit
- Static IP / Dynamic IP
- RADIUS Accounting
- MAC Authentication
Wireless Security
- Captive Portal Authentication
- Access Control
- Maximum Number of MAC Filter: 4,000
- Wireless Isolation Between Clients
- VLAN
- Rogue AP Detection
- WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
- Transmission Power:
- <25dBm (2.4GHz)
- <25dBm (5.0GHz, Band 1 & Band 4)
- <24dBm (5.0GHz, Band 2 & Band 3)
Management Features
- Omada App: Yes
- Centralised Management:
- Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller
- Cloud Access: Yes
Require the Use of an OC300, OC200, Omada Software Controller or an Omada Cloud-Based Controller
- Email Alerts: Yes
- LED ON/OFF Control: Yes
- Management MAC Access Control: Yes
- SNMP: v1, v2c, v3
- System Logging Local / Remote Syslog: Yes
- Web-Based Management: Yes
Others
- Certification: CE, FCC, RoHS, IC
- Environment:
- Operating Temperature: 0~40°C
- Storage Temperature: -40~70°C
- Operating Humidity: 10~90% Non-Condensing
- Storage Humidity: 5~90% Non-Condensing
Shipping Dimensions
- Length: 24.5 cm
- Width: 22.8 cm
- Height: 6.5 cm
- Weight: 0.76 kg
