| HARDWARE FEATURES |
| Standards and Protocols |
IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Interface |
1 x 10/100/1000M Ethernet Port (RJ45) |
| Button |
WPS Button, Reset Button, LED Button, Power Button |
| Power Consumption |
10W（max power consumption） |
| Dimensions ( W x D x H ) |
6.4 x 3.0 x 2.6 in. (163 x 76.4 x 66.5mm) |
| Antenna |
3 x external |
| WIRELESS FEATURES |
| Frequency |
2.4GHz & 5GHz(11ac) |
| Signal Rate |
5GHz:Up to 1300Mbps |
| 2.4GHz:Up to 600Mpbs |
| Reception Sensitivity |
5GHz： |
| 11a 6Mbps:-93dBm@10% PER |
| 11a 54Mbps: -76dBm@10% PER |
| 11ac HT20 mcs8: -68dBm@10% PER |
| 11ac HT40 mcs9: -64dBm@10% PER |
| 11ac HT80 mcs9: -61dBm@10% PER |
| 2.4GHz |
| 11g 54M: -77dBm@10% PER |
| 11n HT20 mcs7: -73dBm@10% PER |
| 11n HT40 mcs7: -70dBm@10% PER |
| Wireless Modes |
Range Extender/Access Point |
| Wireless Functions |
Wireless Statistic |
| Concurrent Mode Boost Both 2.4G/5G WiFi Band |
| Access Control |
| LED Control |
| Domain Login Function |
| Wi-Fi Coverage |
| Wireless Security |
64/128-bit WEP |
| WPA-PSK / WPA2-PSK |
| Transmission Power |
<20dBm(2.4GHz) |
| <23dBm(5GHz) |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
AC1900 Wi-Fi Range Extender RE550 |
| Quick Installation Guide |
| Box Dimensions (W X D X H) |
7.9 x 4.9 x 3.4in. (202x 125 x 86mm) |
| System Requirements |
Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux. |
| Environment |
Operating Temperature: 0°C~30°C (32°F~86°F) |
| Storage Temperature: -40°C~70°C (-40°F~158°F) |
| Operating Humidity: 10%~90% non-condensing |
| Storage Humidity: 5%~90% non-condensing |
