Features
Features 8 PoE+ ports, with total PoE power budget of 58W and useful PoE power management features
- Gigabit Ethernet connections on all ports provide full speed of data transferring
- Integrated security strategy including 802.1Q VLAN, ACL, Port Security and Storm control help protect LAN area investment
- L2/L3/L4 QoS and IGMP snooping optimise voice and video applications
- WEB/CLI managed modes, SNMP, RMON bring abundant management features
- Innovative energy-efficient technology saves up to 50% of power consumption
Specifications
Hardware Features
- Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab,
- IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s,
- IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
- Interface: 8 10/100/1000Mbps RJ45 Ports
- 2 1000Mbps SFP Slots
- (Auto-Negotiation/Auto MDI/MDIX)
- Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
- 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
- 1000BASE-X: MMF, SMF
- Fan Quantity: Fanless
- Power Supply: 100~240VAC, 50/60Hz
- External Power Adapter(Output: 53.5VDC/1.31A)
- Power Consumption: Maximum (PoE on): 75.3W (220V/50Hz)
- Maximum (PoE off): 10.5W (220V/50Hz)
- PoE Ports (RJ45)Standard: 802.3af/at compliant
- PoE Ports: 8 Ports
- Power Supply: 58W*
- Dimensions ( W x D x H ) 209 x 126 x 26mm
Performance
- Bandwidth/Backplane: 20Gbps
- Packet Forwarding Rate: 14.88Mpps
- MAC Address Table8k
- Packet Buffer Memory: 512KB
- Jumbo Frame: 9216 Bytes
Software Features
- Quality of Service: Support 802.1p CoS/DSCP priority
- Support 8 priority queues
- Queue scheduling: SP, WRR, SP+WRR
- Port/Flow- based Rate Limiting
- Voice VLAN
- VLAN: Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)
- Access Control List: L2~L4 package filtering based on source and destination
- MAC address, IP address, TCP/UDP ports, 802.1p,
- DSCP, protocol and VLAN ID
- Time Range Based
- Security: SSH v1/v2
- SSL v2/v3/TLSv1
- Port Security
- Broadcast/Multicast/Unknown unicast Storm Control
- 802.1x and Radius Authentication、IP-Mac-Port-VID Binding、ARP Inspection、DHCP Snooping、DoS Defend
- L2 Switching Features: IGMP Snooping V1/V2/V3
- 802.3ad LACP (Up to 6 aggregation groups,
- containing 4 ports per group)
- Spanning Tree STP/RSTP/MSTP
- BPDU Filtering/Guard
- TC/Root Protect
- Loop back detection
- 802.3x Flow Control
- LLDP(LLDP-MED)
- Management: Web-based GUI and CLI management
- SNMP v1/v2c/v3, compatible with public MIBs and
- TP-LINK private MIBs
- RMON (1, 2, 3, 9 groups)
- CPU Monitoring
- Port Mirroring
- Time Setting: SNTP
- Firmware Upgrade: TFTP & Web
- System Diagnose: VCT
- SYSLOG & Public MIBS
Others
- Certification: CE, FCC, RoHS
- Environment: Operating Temperature: 0~40°C
- Storage Temperature: -40~70°C
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8, MAC OS, NetWare, UNIX or Linux
Shipping Dimensions
- Length: 31.5 cm
- Width: 24 cm
- Height: 7 cm
- Weight: 1.09 kg
