Description
Features
- Built-in 13dBi 2x2 dual-polarized directional MIMO antenna
- Adjustable transmission power from 0 to 23dBm/200mw
- System-level optimizations for more than 15km long range wireless transmission
- TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
- Centralized Management System – Pharos Control
- AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes
- Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely
Specifications
Hardware Features
- Processor: Qualcomm Atheros Enterprise 560MHz CPU, MIPS 74Kc
- Memory: 64MB DDR2 RAM, 8MB Flash
- Interface: 1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in), 1 Grounding Terminal, 1 Reset Button
- Power Supply: Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins)
- Voltage range: 16-27VDC
- Power Consumption: 10.5 Watts Max
- Dimensions ( W x D x H ): 224 x 79 x 60 mm
- Antenna Type: Built-in 13dBi 2x2 Dual-polarized Directional Antenna
- Beam Width: 45° (H-Plane) / 30° (E-Plane)
- Note: For more details, please refer to datasheet
- Protection: 15KV ESD Protection
- 6KV Lightning Protection
- Enclosure: Outdoor ASA stabilized plastic material
- IPX5 waterproof Certification
Wireless Features
- Wireless Standards: IEEE 802.11a/n (with Pharos MAXtream disabled)
- Proprietary Protocol: TDMA Mode (with Pharos MAXtream enabled)
- Wireless Speeds: Up to 300Mbps (40MHz,Dynamic)
- Up to 144.4Mbps (20MHz,Dynamic)
- Up to 72.2Mbps (10MHz,Dynamic)
- Up to 36.1Mbps (5MHz,Dynamic)
- Frequency: 5.15~5.85GHz
Note: Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used.
- Transmission Power: 23dBm/200mw (Adjustable power by 1dBm)
Note: Maximum transmission power may vary across different channels depending on the limitations of the countries or regions in which the device is used.
Software Features
- Wireless Configurations: Pharos MAXtream TDMA Technology
- 802.11a/n Modes
- Selectable Channel Width: 5/10/20/40MHz
- Automatic Channel Selection
- Transmission Power Control
- Dynamic Frequency Selection (DFS)
- WDS Enable/Disable
- Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption
- SSID Broadcast Enable/Disable
- Multi-SSID with VLAN Tagging (AP mode only)
- Distance/ACK Timeout Setting
- Wireless MAC Address Filter
- Wireless Advanced:
- Beacon Interval/RTS Threshold/Fragmentation
- Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
- Management Discovery and Remote Management via Pharos Control application
- HTTP/HTTPS Web-based management
- System Log
- SNMP Agent (v2c)
- Ping Watch Dog
- Dynamic DDNS
- SSH Server
- System Tools: Wireless Signal Quality Indicators:
- Signal Strength/Noise/Transmit CCQ/CPU/Memory
- Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
- Spectrum Analyzer
- Speed Test
- Ping
- Traceroute
- System-level Optimizations: Optimized IGMP Snooping/Proxy for multicast applications
- Hardware watch dog
Poe Adapter Features
- Dimensions (W x D x H): 110*57*33.5mm
- Interfaces: 1 AC Jack with Earth Ground
- 1 10/100Mbps Shielded Ethernet Port (Power + Data)
- 1 10/100Mbps Shielded Ethernet Port (Data)
- Button: Remote Reset Button
- Power Status LEDs: Green
- Input: 100-240VAC, 50/60Hz
- Input Voltage: 100VA~240VAC @ 50Hz~60Hz
- Input Current: 0.4 Max @ 100VAC
- Output: 24VDC, 0.5A Max +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
- Output Voltage: 24VDC (+4,5pins; -7,8pins)
- Efficiency: >80%
- Certifications: CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux
Others
- Certification: CE, FCC, RoHS, IPX5
Shipping Dimensions
- Length: 27 cm
- Width: 13.2 cm
- Height: 10.6 cm
- Weight: 0.78 kg
/
