Features
- Supercharged Performance - Expanded 5.9GHz spectrum support enables additional high-speed 80 and 160MHz channels
- Built for Fast Networking - 2.5GbE port enables support for the fastest ISPs and can optionally be configured as a LAN port
- Secure Network Foundation - Create and define up to 5 separate networks to segregate and contain vulnerable devices
- Granular Management Tools - Parental controls, web filtering, traffic control and threat prevention put you in control over your network
- Simple Remote Access - Comprehensive VPN server solution with remote desktop and site-to-site tunnelling provides flexible and secure remote connectivity
Specifications
Hardware
Cpu
- Quad-Core 1.8GHz
- Hardware Acceleration Engine: Layer 4 / Layer 7
Memory
Antenna Type
- 4× MIMO Omni-Directional High-Gain Dipole (5.0GHz)
- 2× MIMO Omni-Directional High-Gain Dipole (2.4GHz & 5.0GHz)
LAN Port
WAN Port
External Ports
- 1× USB3.2 Gen1 (5V, 0.5A Power Output)
Wireless
IEEE 802.11ax
- 5.0GHz: 1,200Mbps
- 2.4GHz: 600Mbps
- 4×4 160MHz
- Simultaneous Tri-Band Wi-Fi
* Note: 160MHz is Not Supported in Canada and Australia
Wi-Fi Encryption
- WPA/WPA2-Personal
- WPA3-Personal / WPA3-Enterprise
- Wi-Fi Enhanced Open (OWE)
Button and Switch
- WPS, Power, Reset, Wi-Fi On/Off
Physical
- Size (H × W × D): 175 × 230 × 65mm
- Weight: 1kg
- Operating Temperature: 5~40°C
- Storage Temperature: -20~60°C
- Relative Humidity: 5~95% RH
Power
- AC Input Power Voltage: 100~240VAC
- Power Frequency: 50/60Hz, Single Phase
- Power Consumption: 11.1W (Access)
Software (SRM SPECIFICATIONS)
Wireless
- Seamless Roaming: 802.11k/v/r Support
- Guest Network: Yes
- Maximum Number of Wi-Fi SSID: 15×
- Maximum Connected Devices: 200+
Network
- Operating Mode: Wireless AP
- IPv6 Support: Yes
- DHCP Server/Client
- NAT (Network Address Translation): Yes
- QoS (Quality of Service): Yes
- Traffic Control and Traffic Monitor: Yes
- VPN Server: PPTP, OpenVPN, L2TP/IPSec
- VPN Client: PPTP, OpenVPN
Security
- Firewall
- SPI Firewall
- DoS Protection
- Auto Block
- Safe Access (Web Filter, App Filter)
- Threat Prevention
- Intrusion Detection
Management
- Synology Router Manager (SRM)
- QuickConnect and DDNS
- Wake on LAN/WAN
- SNMP
- SSH
- Configuration Backup and Restore
Mobile Apps
- DS Router (Android / iOS)
- VPN Plus (Android / iOS)
- DS File (Android / iOS)
Shipping Dimensions
- Length: 25.5 cm
- Width: 36.6 cm
- Height: 10 cm
- Weight: 1.84 kg
