Features
- High Performance - Over 2,103/1,074MB/s sequential read/write throughput supports stable data transfers
- Easy Expansion - Scale up to 8× drives with one Synology RX418 Expansion Unit
- Flexible Connectivity - Four 1GbE ports support network failover and load balancing, with optional 10/25GbE expansions available
- SSD Cache Support - Boost random IOPS performance with optional SSD cache
Specifications
Hardware
Cpu
- AMD Ryzen V1500B
- 4-Core 2.2GHz
- Hardware Encryption Engine (AES-NI)
Memory
- 8GB DDR4 ECC SODIMM
- Total Memory Slots: 2×
- Maximum Memory Capacity: 32GB (2× 16GB)
Drive Bays
- 8×
- Maximum Drive Bays with Expansion Unit: 18 (2× RX418)
- Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA SSD
- Hot Swappable Drive: Yes
External Ports
- 2× RJ45 1GbE LAN Port (with Link Aggregation / Failover support)
- 2× USB3.2 Gen1 Port
PCIe
- 1× Gen3 x8 Slot (x4 link)
File System
Internal Drives
External Drives
- Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT
Appearance
- Form Factor (RU): 2U
- Rack Installation Support: 4-Post 19" Rack (Synology Rail Kit – RKS-02)
- System Fan: 40mm × 3pcs
Power and Environment
Power Supply
AC Input Power Voltage
- 100–240VAC
- 50/60Hz, Single Phase
Power Consumption
- 47.67W (Access) / 17.43W (HDD Hibernation)
Operating Temperature
Storage Temperature
Relative Humidity
Dsm Specifications
Storage Management
- Maximum Single Volume Size: 108TB
- Btrfs (Write-Once): Yes
- SSD TRIM: Yes
- Supported RAID Types: Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
File Services
- Maximum Concurrent SMB/AFP/FTP Connections: 1,000+
- Windows ACL Integration: Yes
- NFS Kerberos Authentication: Yes
Accounts and Shared Folder
- Maximum Local User Accounts: 2,048×
- Maximum Local Groups: 256×
- Maximum Shared Folders: 512×
Virtualisation and Enterprise Integration
- VMware vSphere
- Microsoft Hyper-V
- Citrix
- OpenStack
Backup and Data Protection
- Hyper Backup
- Snapshot Replication
- Synology High Availability
- Active Backup for Business
Surveillance Station
Maximum IP Cameras (H.264)
- 720p: 40× channels, 1,200 FPS
- 1080p: 40× channels, 600 FPS
- 3M: 40× channels, 480 FPS
- 5M: 40× channels, 320 FPS
- 4K: 20× channels, 200 FPS
Warranty
- 3-Year Hardware Warranty (Extendable to 5-Years with EW202)
Shipping Dimensions
- Length: 57 cm
- Width: 54 cm
- Height: 18 cm
- Weight: 9.68 kg
