Features
- High Performance - Supports critical workloads with up to 2,200MB/s read and 1,164MB/s write performance
- Redundant Power - Maximise uptime with two redundant power supply units
- Expansion Options - Scale up to 28× drives with the RX1217(RP) and add 10/25GbE networking or fast NVMe SSD Cache with PCIe add-on cards
- High Availability - Combine two devices into a Synology High Availability cluster for maximum service uptime and minute-level failover
Specifications
Hardware
Cpu
- AMD Ryzen V1500B Quad-Core 2.2GHz
- Hardware Encryption Engine: Yes (AES-NI)
Memory
- 4GB DDR4 ECC UDIMM (Expandable up to 32GB)
Drive Bays
- 16× 3.5" / 2.5" SATA HDD/SSD (Drives Not Included)
- Hot Swappable Drive: Yes
- Only Synology SNV3400/3500 M.2 SSDs (Sold Separately) Can Be Used for SSD Cache
External Ports
- 2× USB3.2 Gen1 Ports
- 1× Expansion Port (Infiniband)
LAN Ports
- 4× 1GbE RJ45
- Wake on LAN / WAN: Yes
PCIe
- 1× 4-Lane x8 Slot
- Supports Network Interface Cards and M.2 NVMe SSD Adapter Cards for SSD Cache
Form Factor
- Rackmount 3U
- 4-Post 19" Rack Installation Support
Size (H × W × D)
- 132.3 × 482 × 656.5 mm (with Server Handles)
Weight
Cooling
- 3× (80 × 80 × 32mm) System Fans
Power
- AC Input Power Voltage: 100–240VAC
- Power Frequency: 50/60Hz, Single Phase
- Scheduled Power On/Off: Yes
Environment
- Operating Temperature: 0~35°C
- Storage Temperature: -20~60°C
- Relative Humidity: 5~95% RH
- Maximum Operating Altitude: 5,000m
General Dsm Specification
Networking Protocols
- SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP)
File Systems
- Internal: Btrfs, ext4
- External: Btrfs, ext4, ext3, FAT32, NTFS, HFS+, exFAT
Supported RAID Types
- Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Storage Management
- Maximum Single Volume Size: 108TB
- Maximum System Snapshots: 65,536×
- Maximum Internal Volumes: 64×
- SSD Cache: Read/Write Cache Support (2.5" SATA SSD / M.2 NVMe SSD Support)
File Sharing Capabilities
- Maximum Local User Accounts: 2,048×
- Maximum Local Groups: 256×
- Maximum Shared Folders: 512×
- Maximum Concurrent SMB/NFS/AFP/FTP Connections: 1,000+
Virtualisation
- VMware vSphere
- Microsoft Hyper-V
- Citrix
- OpenStack
Security
- Firewall, Shared Folder Encryption, SMB Encryption, FTP over SSL/TLS, SFTP, Rsync over SSH, Login Auto Block, Let’s Encrypt Support, HTTPS (Customisable Cipher Suite)
Data Protection and Backup
- Hyper Backup
- Snapshot Replication (32× Maximum Replications)
- Synology High Availability
- Active Backup for Microsoft 365
- Active Backup for Google Workspace
- Active Backup for Business
Surveillance
- Maximum IP Cameras: 40×
- Total of 1,200fps @720p (H.264)
Warranty and Environment
Shipping Dimensions
- Length: 76.5 cm
- Width: 25 cm
- Height: 57.4 cm
- Weight: 22.29 kg
