Features
- Dependable Performance - Up to 2,239/1,573MB/s sequential read/write throughput supports office wide applications
- Fast and Flexible Networking - Built-in 2.5GbE ports, supports 10GbE SFP+/RJ45 and 25GbE SFP28 adapter cards
- Simple Expansion - Scale up on demand to with two DX525 expansion units for up to 18-drive bays and 360TB of raw storage
- Comprehensive Backups - Protect your IT infrastructure with license-free solutions for backup, replication and recovery
- Long-Term Support - Backed by Synology's 3-year limited hardware warranty, extendable to 5-years in select markets
Specifications
Performance
- CPU: AMD Ryzen V1500B, Quad-Core 2.2GHz, 64-bit
- Hardware Encryption Engine: Yes (AES-NI)
- Memory: 8GB DDR4 ECC SODIMM (Expandable up to 32GB)
Storage
- Drive Bays: 8× 3.5"/2.5" SATA HDD/SSD
- Maximum Drive Bays with Expansion: up to 18×
- M.2 NVMe Slots: 2× M.2 2280 NVMe (SSD Cache Support)
- Hot-Swap Drives: Yes
- Supported RAID: Basic, JBOD, RAID 0, 1, 5, 6, 10, Synology Hybrid RAID
- Maximum Single Volume Size: 200TB (With Expanded Memory)
Network and Expansion
- LAN Ports: 2× 1GbE RJ45
- PCIe Slot: 1× Gen3 x8 (Supports 10GbE Network Upgrade Card)
- USB Ports: USB3.2 Gen1
- Expansion Ports: 2× USB Type-C
Performance and Scalability
- Maximum Concurrent SMB Connections: 500+
- Maximum iSCSI Targets: 128×
- Maximum LUNs: 256×
- Maximum Local Users: 2,048×
- Maximum Shared Folders: 512×
Enterprise and Business Features
- Btrfs File System: Supported
- Snapshot Replication: Yes
- Synology High Availability: Supported
- Virtual Machine Manager: Supported
- Active Backup Suite: Supported
- Hardware-Accelerated Encryption: Yes
Surveillance Station
- Default Camera Licences: 2×
- Scalable IP Camera Deployment: Suitable for Mid-Sized Surveillance Environments
Power and Physical
- Power Supply: 250W
- AC Input: 100~240V AC
- Cooling: Dual Fan System
- Dimensions (H × W × D): 166 × 343 × 243mm
- Weight: Approx. 6kg (Without Drives)
Environment
- Operating Temperature: 0~40°C
- Humidity: 5~95% RH
Warranty
- 3-Year Hardware Warranty (Extendable with Extended Warranty Plus)
Shipping Dimensions
- Length: 44 cm
- Width: 34 cm
- Height: 28.1 cm
- Weight: 7.50 kg
