Features
- Accelerated Performance - Delivers over 2,100MB/s read and 1,400MB/s sequential write performance
- Easy Capacity Expansion - Double storage capacity to 24× drive bays with one 12-bay DX1222 expansion unit
- Supports Demanding Applications - Leverage up to 32GB memory, 10/25GbE networking or NVMe SSD Cache to boost read and write speed
Specifications
Performance
- CPU: AMD Ryzen V1500B Quad-Core 2.2GHz, 64-bit
- Hardware Encryption Engine: Yes (AES-NI)
- Memory: 4GB DDR4 ECC UDIMM (Expandable up to 32GB)
Storage
- Drive Bays: 12× 3.5"/2.5" SATA HDD/SSD
- Maximum Drive Bays with Expansion: up to 24× (With Expansion Units)
- Hot-Swap Drives: Yes
- Supported RAID: Basic, JBOD, RAID 0, 1, 5, 6, 10, Synology Hybrid RAID
- Maximum Single Volume Size: 108TB (200TB with Expanded Memory)
Network and Expansion
- LAN Ports: 4× 1GbE RJ45
- PCIe Slot: 1× Gen3 x8 (Supports 10GbE Network Upgrade Card)
- USB Ports: USB3.2 Gen1
- Expansion Port: 1× Mini-SAS HD
Performance and Scalability
- Maximum Concurrent SMB Connections: 1,000+
- Maximum iSCSI Targets: 128×
- Maximum LUNs: 256×
- Maximum Local Users: 2,048×
- Maximum Shared Folders: 512×
Enterprise and Data Protection Features
- Btrfs File System: Snapshot and advanced data integrity
- Snapshot Replication: Yes
- Synology High Availability: Supported
- Virtual Machine Manager: Supported
- Active Backup Suite: Supported
Surveillance Station
- Default Camera Licences: 2×
- Scalable IP Camera Deployment: Suitable for Enterprise Surveillance Environments
Power and Physical
- Power Supply: 250W
- AC Input: 100~240V AC
- Cooling: Dual Fan System
- Dimensions (H × W × D): 270 × 300 × 340mm (Approx.)
- Weight: Approx. 9kg (Without Drives)
Environment
- Operating Temperature: 0~40°C
- Humidity: 5~95% RH
Warranty
- 3-Year Hardware Warranty (Extendable to 5-Years with EW202 or Extended Warranty Plus)
Shipping Dimensions
- Length: 45.5 cm
- Width: 42 cm
- Height: 40 cm
- Weight: 12.62 kg
