LineSplit Fibra
Manufacturer overview
Module to split one Fibra line into four lines
Design security systems freely with Superior LineSplit Fibra. LineSplit brings a new level of flexibility into the installation process. There is no need to replace wiring if you want to replace an outdated security system with Ajax. The module can be installed at any point of the Fibra line (even after another LineSplit (1) ). It splits one Fibra line into four and extends each one of them by 2,000 m (2) . LineSplit inherits all the advantages of Ajax smart devices: it is easy to control the module from the app, receive event notifications, and configure or test LineSplit remotely.
One device, two missions. LineSplit provides enhanced flexibility during the installation of a security system. Devices can be installed safely, reducing cable and installation costs. LineSplit can also provide a separate line for each connected device.
Easy to mount into Case. LineSplit is inserted into Case. This casing has an optimal arrangement of wire channels, special holders for the module, and the tamper. Several variations of casings are available.
Unique wired technology. Fibra is proprietary Ajax technology for secure two-way communication between devices and a hub or module that extends the Fibra line. Fibra features encryption and device authentication to prevent sabotage, spoofing, and data theft. The Fibra line supports all types of devices, including sirens, keypads, and detectors with photo verification.
Energy efficiency as a priority. The module consumes up to 0,22 W at peak consumption times. With such low power consumption, an installer can connect more devices to a Fibra line and lengthen the wired connectivity.
Sabotage resistance. The casing where LineSplit is installed has a tamper that warns a monitoring company and system users about an attempt to open Case or remove the device from the mounting panel.
Specifications
| Line connection |
4-core cable |
| Connection |
to any point of the Fibra line |
| Wired connection range |
up to 6,500 ft |
| Number of output lines |
4 |
| Number of input lines |
1 |
| Protection against spoofing |
Device authentication |
| Lost connection detection |
In 36 seconds |
| Device’s operating voltage range |
6−30 V⎓, up to 440 mW |
| Nominal operating voltage |
24 V⎓ |
| Quiescent device current consumption at nominal voltage |
1.9 mA |
| Maximum device current consumption at nominal voltage |
18.3 mA |
| Cable length |
up to 6,500 ft |
| Dimensions |
3.54″ × 1.97″ × 0.59″ |
| Weight |
0.6 oz |
| Operating temperature range |
from 14 °F to 104 °F |
| Operating humidity |
up to 75% |
| Warranty |
24 months |
