LightCore (1-Gang)
Manufacturer overview
Smart touch 1-gang light switch
LightSwitch (1-gang) Jeweller won the Red Dot Design Award. The smart light switch combines the reliability of professional security systems and a thoughtful user experience. The entire panel is sensitive to touch and even the hand approaching (at a distance of 15 mm). LightSwitch is good to use in the dark thanks to its soft backlight. The 1-gang light switch can do more than just turn on lighting fixtures. It can also simulate the owner's presence and control curtains or blinds remotely with automation scenarios.
Comfort and security in a touch. The smart light switch combines the reliability of professional security systems and a thoughtful user experience. The entire panel is sensitive to touch and even the hand approaching (at a distance of 15 mm). LightSwitch is good to use in the dark thanks to its soft backlight. The 1-gang light switch can do more than just turn on lighting fixtures. It can also simulate the owner's presence and control curtains or blinds remotely with automation scenarios.
Designed for any interior. LightSwitch is enchanting with its laconic design and high-end quality hardware. The device will become an appropriate part of a cozy home environment or a high-tech space equally. Highlight the switch on the wall or make it invisible. The appearance is universal and suitable for installation everywhere — at home, in the office, production facility, or in any other area.
Enjoy the lighting control. Turn off the light with minimal effort. The entire panel is touch-sensitive and reacts even to reaching the hand, elbow, knee, or another body part less than 15 mm close. This function is indispensable if you want to avoid touching the device or if it's in a public place. At the same time, the touch panel reacts only when it is needed.
Smart features with real value. LightSwitch improves the concept of lighting. It isn't just a standard switch, although it has the straightforward setup and ease of use you'd expect from an Ajax product.
Automation for comfort and security. Set the light to turn off automatically when arming the system or in case of an emergency. Or turn on the light according to a schedule.
Specifications
| Relay |
LightCore (1-gang) Jeweller |
| Radio frequency bands |
866.0–866.5 MHz 868.0–868.6 MHz 868.7–869.2 MHz 905.0–926.5 MHz 915.85–926.5 MHz 921.0–922.0 MHz |
| Maximum effective radiated power (ERP) |
up to 20 mW |
| Radio signal modulation |
GFSK |
| Radio communication range |
up to 3,600 ft |
| Power of switched device |
from 5 to 600 W |
| Protection against spoofing |
device authentication |
| Communication loss detection |
after 36 s |
| Power supply voltage |
230 V~, 50/60 Hz |
| Average consumption |
up to 200 mW |
| Maximum power |
600 W |
| Current protection |
more than 2.6 A |
| Protection class |
IP20 |
| Form factor of the switch |
European type (55) |
| Touch-sensitive panels |
SoloButton (1-gang) — 3.26" × 3.26" × 0.4" |
| Frames |
Frame (2 seats) — 3.26" × 6.04" × 0.25" |
| Temperature protection |
more than 140 °F |
| Operating temperature range |
from 14 °F to 104 °F |
| Operating humidity |
Up to 75% with no condensation |
| Warranty |
24 months |
