Description
Features
- 1/2.8" Progressive Scan CMOS
- 2.8-8mm motorized lens
- 25fps/30fps@2MP(1920*1080)
- Triple Streams
- Smart IR Up to 20m
- Low bitrate, Excellent low light performance
- WDR,3D DNR
- ROI, Defog, HLC, Corridor mode, DIS
- IP66
Specifications
Camera
- Image Sensor: 1/2.8" Progressive Scan CMOS
- Effective Pixels: 1920(H)×1080(V)
- Scanning System: Progressive
- Electronic Shutter: 1/5-1/20000s
- Min. illumination Colour 0.01Lux @(F1.2,AGC ON), B/W 0Lux @(IR LED ON)
- S/N Ratio: 55dB
- IR Range: Up to 20m
- IR On/Off Control: Auto/ Manual
- IR LEDs: 3pcs
- Pan/Tilt/Pan: 0˚~350˚, Tilt:0˚~90˚
- SpeedPan: 0.1~120°/s ; Tilt:0.1~120°/s
Lens
- Lens Type: Motorized
- Iris: Fixed Iris
- Focal Length: 2.8~8mm
- F Number: F1.6
- Angle of View: 103.5°~ 50°
- Focus Control: Motorized
- Close Focus Distance: 0.2m
Video
- Compression: H.265,H.265,MJPEG
- Max. Resolution: 1080p (1920×1080)
- Streaming Capability: 3 Streams
- Stream1: 1920×1080/1280×720 @25/30fps
Frame Rate
- Stream2: D1/VGA/640×360/CIF/QVGA @25/30fps
- Stream3: VGA/CIF/QVGA @25/30fps
- Bit Rate Control: CBR/VBR
Bit Rate
- Stream1: 500kbps~12000kbps
- Stream2: 100kbps~6000kbps
- Stream3: 100kbps~3000kbps
- Day/Night: ICR
- Image Enhancement: HLC / Defog / WDR (96dB)
- White Balance: Support
- Gain Control: Auto/Manual
- Noise Reduction: 2D/3D DNR
- Electronic Image Stabilization(EIS): Support
- Smart IR: Support
- Mirror: Support
- Region of Interest: Support
- Motion Detection: Support
- Privacy Masking: Support
Audio
- Compression: N/A
- Bit Rate: N/A
Network
- Protocols: IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP
- Interoperability: ONVIF
- Streaming Method: Unicast
- Max. User Access: 10 Users
- Web Viewer:
- Management Software: IMS 3.0
- Smart Phone: IOS, Android
Intelligence
- IVSPerimeter, Single Virtual Fences, Double Virtual Fences, Loiter, Multi Loiter, Object Left, Object Removed, Abnormal Speed, Converse, Illegal Parking, Signal Bad
Interface
- Ethernet:1 Ethernet (10/100 Base-T) RJ-45 Connector
- Audio Interface: N/A
- Alarm: N/A
- RS485: N/A
- BNC Output: N/A
- Reset Button: Built-in
- Edge Storage: N/A
Electrical
- Power Supply DC 12V / POE
- Power Consumption: 2W(IR LED OFF), 4.5W (IR LED ON)
Operating Temperature
- Starting Temperature: -30°C ~ 50°C
- Working Temperature: -30°C ~ 50°C
- Operating Humidity: Less than 90% RH
- Ingress Protection: IP66
- Certifications: CE / FCC
- Casing: Metal
- Dimensions: φ105×73mm
- Net Weight: 450g
Shipping Dimensions
- Weight: 0.70 kg
