Description
Features
- 1/2.5" progressive scan CMOS
- 3.3~12mm motorized lens
- 30fps@4K(3840×2160)
- Triple streams
- WDR, 3D DNR, ROI, HLC, BLC, Aisle mode, Defog
- Smart IR up to 30m
- IP66, IK10
Specifications
Camera
- Image Sensor: 1/2.5" Progressive Scan CMOS
- Effective Pixels: 3840(H)×2160(V)
- Electronic Shutter: 1/5-1/20,000s
- Min. illumination: Colour: 0.01 Lux @(F1.2,AGC ON), B/W: 0 Lux @(IR LED ON)
- S/N Ratio: 55dB
- Day/Night: ICR
- Wide Dynamic: WDR (120dB)
Range
- IR Range: Up to 30m
- IR On/Off Control: Auto/ Manual
- IR LEDs: 15pcs
- Pan/Tilt/Rotation Range: Pan: 0˚~355˚, Tilt: 0˚~80˚, Rotation: 0˚~355˚
Lens
- Lens Type: Motorised
- Iris: Fixed Iris
- Focal Length: 3.3~12mm
- F Number: F1.4
- Angle of View: 108.6° ~ 35°
- Focus Control: Motorised
Video
- Compression: H.265, H.264, MJPEG
- Max. Resolution: 8MP (3840×2160)
- Streaming Capability: 3 Streams
- Stream1: 3840×2160 / 3072×2048 / 2592×1520 / 1920×1080 @25/30fps
Frame Rate
- Stream 2: D1 / VGA / CIF / QVGA @25/30fps
- Stream 3: VGA / CIF / QCIF @25/30fps
- Bit Rate Control: CBR/VBR
Bit Rate
- Stream 1: 500kbps~16Mbps
- Stream 2: 10Kbps~6Mbps
- Stream 3: 10Kbps~3Mbps
- Image Enhancement: HLC / BLC / Anti-shake / Defog / WDR (120dB)
- White Balance: Support
- Gain Control: Auto/Manual
- Noise Reduction: 2D/3D DNR
- Smart IR: Support
- Mirror: Support
- Aisle Mode: Support
- Region of Interest: Support
- Motion Detection: Support
- Privacy Masking: Support
Audio
- Compression: G.711, RAW_PCM
- Bit Rate: 8kbps, 16kps, 64kbps
Network
- Protocols: IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP
- Interoperability: ONVIF, SDK, CGI
- Streaming Method: Unicast
- Max. User Access: 10 Users
- Web Viewer:
- Management Software: SunView
- Smart Phone: iOS, Android
Intelligence
- IVS: Perimeter, Single Virtual Fence, Double Virtual Fences, Loiter, Multi Loiter, Object Left, Object Removed, Abnormal Speed, Converse, Illegal Parking, Signal Bad
Interface
- Ethernet: 1 Ethernet (10/100 Base-T) RJ-45 Connector
- Audio: 1ch Input, 1ch Output
- Alarm: 1ch Input, 1ch Output
- CVBS Output: N/A
- Reset Button: Support
- Storage: Built-in Micro SD/SDHC/SDXC slot, up to 128G
Electrical
- Power Supply: DC12V/POE (IEEE 802.3af)
- Power Consumption: 3.5W (IR LED OFF), 8W (IR LED ON)
- Operating Temperature: -30°C ~ 50°C
- Operating Humidity: Less than 90% RH
- Ingress Protection: IP66, IK10
- Certifications: CE / FCC
- Casing: Metal
- Dimensions: φ130 × 112mm
- Net Weight: 690g
Shipping Dimensions
- Weight: 0.90 kg
