Description
Features
- 1/2.8" Progressive Scan CMOS
- Motorized lens 2.7~12mm
- 25fps/30fps@1080P(1920*1080)
- Supporting EU+CIS number plates
- Recognition rate of 97% or higher
- Max recognition speed of 50km/h
- 3D DNR, WDR, ICR
- ROI, Defog, HLC, DIS
- Smart IR Up to 60m
- IP67
Specifications
Camera
- Image Sensor: 1/2.8" Progressive Scan CMOS
- Effective Pixels: 1920(H)×1080(V)
- Electronic Shutter: 1/5-1/20,000s
- Min. illumination: Colour: 0.001Lux @(F1.2,AGC ON), B/W: 0Lux @(IR LED ON)
- S/N Ratio: 55dB
- Day/Night ICR
- Wide Dynamic Range: Ture WDR >120dB
- IR Range: Up to 60m
- IR On/Off Control: Auto/ Manual
- IR LEDs: 8pcs
- Pan/Tilt/Rotation Range: Pan: 0˚~360˚, Tilt: 0˚~90˚, Rotation: 0˚~360˚
Lens
- Lens Type: Motorized
- Iris: Auto Iris
- Focal Length: 2.7~12mm
- F Number: F1.3
- Angle of View: 105°~ 32°
- Focus Control: Motorized
Video
- Compression: H.265, H.264, MJPEG
- Max. Resolution: 1080p (1920×1080)
- Streaming Capability: 3 Streams
- Stream /Stream 1: 1920×1080/1280×720 @25/30fps
- Frame Rate: Stream2: D1/VGA/640×360/CIF/QVGA @25/30fps
- Stream 3: VGA/CIF/QVGA @25/30fps
- Bit Rate Contro: lCBR/VBR
- Bit Rate: Stream1: 200kbps~12000kbps
- Stream 2: 100kbps~6000kbps
- Stream 3: 100kbps~6000kbps
- Image Enhancement: HLC / BLC / Anti-shake / Defog / WDR (>120dB)
- White Balance: Support
- Gain Control: Auto/Manual
- Noise Reduction: 2D/3D DNR
- Smart IR: Support
- Mirror: Support
- Aisle Mode: Support
- Region of Interest: Support
- Motion Detection: Support
- Privacy Masking: Support
Audio
- Compression: G.711 ,RAW_PCM
- Bit Rate: 64kbps (G.711), 128kps (RAW_PCM)
Network
- Protocols: IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP
- Interoperability: ONVIF, SDK, CGI
- Streaming Method: Unicast
- Max. User Access: 10 Users
- Web Viewer:
Management Software: SunView
- Smart Phone: iOS, Android
Intelligence
- Intelligent Video: Embed ANPR, Marx recognition speed of 50Km/h, 1000 whitelist & black list, FTP image upload
Interface
- Ethernet: 1 Ethernet (10/100 Base-T) RJ-45 Connector
- Audio: 1ch Input, 1ch Output
- Alarm: 1ch Output
- RS485: Support
- CVBS Output: N/A
- Reset Button: Support
- Storage: Built-in Micro SD/SDHC/SDXC slot, up to 128G
Electrical
- Power Supply: DC12V/POE (IEEE 802.3af)
- Power Consumption: 4W (IR LED OFF), 8W (IR LED ON)
- Operating Temperature: Starting Temperature: -30°C ~ 60°C (-22°F ~ 140°F )
Working Temperature: -40°C ~ 60°C (-40°F ~ 140°F)
- Operating Humidity: Less than 90% RH
- Ingress Protection: IP67 (IK10 optional)
- Certifications: CE / FCC
- Casing: Metal
- Dimensions: φ110×375.5mm
- Net Weight: 1680g
Shipping Dimensions
- Weight: 1.90 kg
