Description
Features
- 1/2.8″ progressive scan CMOS
- 12x optical zoom,16x digital zoom
- 5MP(2560×1920)@25/30fps
- Multiple streams
- 3D DNR, WDR, ICR, IVS, Defog
- Auto tracking
- Smart IR range up to 80m
- IP66
Specifications
Camera
- Image Sensor: 1/2.8" Progressive Scan CMOS
- Effective Pixels: 2560(H) x 1920(V)
- Electronic Shutter: Auto/Manual, 1/5-1/20,000s
- Min. Illumination: Colour: 0.01 Lux @(F1.2,AGC ON), B/W: 0 Lux @(IR LED ON)
- S/N Ratio: 55dB
- Day/Night: Auto(ICR) / Day / Night / Timing
- Wide Dynamic: WDR (120dB)
- IR Range: up to 80m
- IR On/Off Control: Auto/ Manual
- IR LEDs: 6pcs
Lens
- Focal Length: 4.7~56.4mm
- Max. Aperture: F1.6~F3.0
- Angle of View: H: 60.9°~6.43°, V: 40.1°~4.1°
- Optical Zoom: 12x
- Digital Zoom: 16x
- Focus Control: Auto/Manual
Ptz
- Pan/Tilt Range: Pan: 0° ~ 360° endless, Tilt: -10° ~ +90°
- Manual Control Speed: Pan: 0.1° ~180° /s, Tilt: 0.1° ~90° /s
- Preset Speed: Pan: 180° /s, Tilt: 90° /s
- Presets: 300
- PTZ Mode: 6 Track, 12 Tour, 12 Scan,
- Speed Setup: Auto/Manual (0-8)
- Power up Action: Support
- Idle Motion: Activate Preset/ Scan/ Tour/ Track if there is no command in the specified period
Video
- Compression: H.265, H.264, MJPEG
- Max. Resolution: 5MP (2560×1920)
- Streaming Capability: 3 Streams
- Stream /Stream 1: 2560×1920/2048×1536/1280×960 @25/30fps
- Frame Rate: Stream 2: D1/VGA/640×360/CIF/QVGA @25/30fps
- Stream 3: VGA/CIF/QVGA @25/30fps
- Bit Rate Control: CBR/VBR
- Bit Rate: Stream1: 200kbps~12Mbps
- Stream 2: 100kbps~6Mbps
- Stream 3: 100kbps~3Mbps
- Image Enhancement: HLC / BLC / Anti-shake / Defog / WDR (120dB)
- White Balance: Auto/Tungsten/Fluorescent/Daylight/Shadow/Manual
- Gain Control: Auto/Manual
- Noise Reduction: 2D/3D DNR
- Smart IR: Support
- Mirror: Support
- Aisle Mode: Support
- Region of Interest: Off / On (8 Zone)
- Motion Detection: Off / On
- Privacy Masking: Off / On (4 Area, Rectangle)
Audio
- Compression: G.711, RAW_PCM
- Bit Rate: 8kbps (G.711), 16kps (RAW_PCM)
Network
- Protocols: IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP
- Interoperability: ONVIF, SDK, CGI
- Streaming Method: Unicast
- Max. User Access: 10 Users
- Edge Storage: NAS
- Local PC for instant recording
- MicroSD Card: up to128GB
- Web Viewer:
- Management Software: SunView
- Smart Phone: iOS, Android
Intelligence
- Auto Tracking: Support
- IVS: Perimeter, Single Virtual Fence, Double Virtual Fences, Loiter, Multi Loiter, Object Left, Object Removed, Abnormal Speed, Converse, Illegal Parking, Signal Bad
Interface
- Ethernet: 1 Ethernet (10/100 Base-T) RJ-45 Connector
- Audio: 1ch Input, 1ch Output
- Alarm: 2ch Input, 1ch Output
- RS485: N/A
- CVBS Output: N/A
- Reset Button: Yes (Built-in)
Electrical
- Power Supply: AC24V/PoE+ (IEEE 802.at)
- Power Consumption: Less than 25W
- Operating Temperature: Starting Temperature: -40°C ~ 60°C,
Working Temperature:-55°C ~ 60°C,
- Operating Humidity: Less than 90% RH
- Ingress Protection: IP66, TVS4000V
- Certifications: CE/FCC
- Casing: Metal
- Dimensions (L × W × H): 146.6 × 139.3 × 218.3mm
- Net Weight: 1.5kg
Shipping Dimensions
- Weight: 1.70 kg
