Description
Features
- Four 1/1.8" 8MP Progressive Scan CMOS
- H.265/H.264 Triple-stream encoding
- Edge stitching 25fps@7680×4320
- 720°Panoramic View
- Unique De-warping Image
- Support Camera & Software De-warping
- ROI, Defog, HLC, BLC, AWB, AGC, EIS, IVS
- IP66
Specifications
Camera
- Image Sensor: Four 1/1.8" 8MP Progressive Scan CMOS
- Effective Pixels: 7680(H)×4320(V)
- Scanning System: Progressive
- Electronic Shutter: 1/5-1/20,000s
- Min. illumination: Colour: 0.002 Lux @(F2.2, AGC ON), B/W: 0.0002 Lux @( F2.2, AGC ON)
S/N Ratio: ≥55dB
- IR Range: N/A
- IR On/Off Control: N/A
- IR LEDs: N/A
- Pan/Tilt/Rotation Range: N/A
Lens
- Lens Type: Fixed
- Iris: Fixed Iris
- Focal Length: 2.2mm
- F Number: F2.2
- Angle of View: 360°×360°
- Focus Control: Fixed
- Close Focus Distance: N/A
Video
- Compression: H.265, H.264, MJPEG
- Max. Resolution: Edge stitching 7680×4320
- Streaming Capability: 3 Streams
- Stream /Stream1: 7680×4320 @25fps, 5760×3240/3840×2160 @25fps/30fps
- Frame RateStream: 2: 2560×1440/1080p/D1 @25fps/30fps
- Stream3: 720P/640×360/D1 @25fps/30fps
- Bit Rate Control: CBR/VBR
- Bit RateStream 1: 500Kbps~16Mbps
- Stream 2: 500Kbps~12Mbps
- Stream 3: 100Kbps~8Mbps
- Day/Night: Colour
- Image Enhancement: DWDR / BLC / HLC / Defog
- White Balance: Auto/Manual
- Gain Control: Auto/Manual
- Noise Reduction: 2D/3D DNR
- Electronic Image Stabilization: (EIS)Support
- Smart IR: N/A
- Mirror: N/A
- Region of Interest: Support
- Motion Detection: Support
- Privacy Masking: Support
- Video Mode: Full Screen Stretch, 360° Panorama, Crystal Ball, Asteroid, Auto Cruise
Audio
- Compression: G.711
- Bit Rate: 64kbps (G.711), 128kps (RAW_PCM)
Network
- Protocols: IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, APR, SNMP
- Interoperability: ONVIF
- Streaming Method: Unicast
- Max. User Access: 10 Users
- Web Viewer:
- Management Software: SunView
- Smart Phone: iOS, Android(>V4.3)
Intelligence
- IVS: Perimeter, Single Virtual Fences, Double Virtual Fences, Loiter, Multi Loiter, Object Left, Object Removed, Abnormal Speed, Converse, Illegal Parking, Signal Bad, Audio Anomaly Detection
Interface
- Ethernet: 1 Ethernet (1000 Base-T) RJ-45 Connector
- Audio: 1ch Audio In, 1ch Audio Out, 2ch Built-in MIC
- Alarm: 1ch Alarm In, 1ch Alarm Out
- RS485: N/A
- BNC Output: N/A
- Reset Button: Support
- Edge Storage: N/A
Electrical
- Power Supply: DC12V / POE+
- Power Consumption: Max. 10W
- Operating Temperature: -30°C ~ 60°C
- Working Temperature: -40°C ~ 60°C
- Operating Humidity: Less than 90% RH
- Ingress Protection: IP66
- Certifications: CE / FCC
- Casing: Metal
- Dimensions: 112.2×112.2×90mm
- Net Weight: 1.25kg
Shipping Dimensions
- Weight: 1.00 kg
