Description
Features
- Supports AHD/TVI/CVI/CVBS/IP video inputs
- Supports VGA, HD-OUT, CVBS output
- Easy to use Same Interface of GUI/WEB/Client
- Support various mobile monitoring:(IOS, Android)
- Support more than languages
- Perfect protection circuit, unique triple watchdog function
- Supporting web, IMS, provide SDK development
Specifications
System
- Main Processor: Embedded processor
- Operating System: Embedded LINUX
Video and Audio
- Analogue Camera Input: 8ch BNC
- AHD Camera: 1080p / 720p / 960H @25/30fps
- TVI Camera: 1080p / 720p / 960H @25/30fps
- CVI Camera: 1080p / 720p / 960H @25/30fps
- CVBS Camera: PAL/NTSC
- IP Camera Input: 8ch, each channel up to 1080p
- Audio In/Out: 8ch input, 1ch output, RCA
Two-way Talk: N/A
Display
- Interface: 1ch HD-OUT, 1ch VGA, 1ch CVBS
- Resolution: HD-OUT: 1920×1080, 1280×1024, 1440×900
- Resolution: VGA: 1920×1080, 1280×1024, 1440×900
- Multi-screen Display: 1/4/9
Recording
- Compression: H.264 High Profile
- Resolution: 1080p/720p/960H
- Record Rate: 1080p @12fps、960H (1~25/30fps)
- Bit Rate: 1Kbps ~ 6144Kbps Per Channel
- Record Mode: Manual, Event, Timer
- Record Interval: Post-record: 5 ~ 60s
Video Detection and Alarm
- Trigger Events: Recording, Buzzer, Push Message, Popup Message
- Video Detection: Motion Detection, Video Loss, Camera Tamper
- Alarm in/out: 4/1
Network
- Interface: 1 RJ-45 port (10/100Mbps)
- Network Function: HTTP, TCP/IP, UDP, NTP, DHCP, DNS, IP Filter, DDNS,
- Max. User Access: Access 5 users
- Smart Phone: iPhone, iPad, Android
- Interoperability: ONVIF 2.6, SDK
Playback and Backup
- Playback: 8/4/1
- Search Mode: Time /Date, Alarm, Picture Grid, Event
- Playback Function: Play, Pause, Stop, Next Frame, Fast play, Slow Play, Layout, Shuffle, Backup Selection, Digital Zoom
- Backup Mode: USB HDD
Storage
- Internal HDD: 2 SATA Ports, up to 6TB for each HDD
- Mounting Mode: Embedded
- eSATA: N/A
Interface
- USB Ports: 2× USB2.0
- RS232: N/A
- RS485: 1 Port, for PTZ Control
General
- Power Supply: DC12V 4A
- Power Consumption: Max. 10W (without HDD)
- Operating Temperature: -10°C ~ 50°C
- Strorage Conditions: Less than 90% RH
- Certifications: CE/FCC
- Dimensions (L × W × H): 350 x 305 x 49mm
- Net Weight: 1900g
Shipping Dimensions
- Weight: 2.10 kg
