Description
Features
- Supports AHD/TVI/CVI/CVBS/IP video inputs
- VGA, HDMI video output up to 4K
- Smart search / playback
- Response Time ≤0.2s
- Easy to use same Interface of GUI/WEB/Client
- Support more than languages
- Perfect protection circuit, unique triple watchdog function
Specifications
System
- Main Processor: Embedded processor
- Operating System: Embedded LINUX
Video and Audio
- Analogue Camera Input: 4ch BNC
- AHD Camera: 5MP/4MP/3MP/1080p/720p @25/30fps
- TVI Camera: 5MP/4MP/3MP/1080p/720p @25/30fps
- CVI Camera: 5MP/4MP/3MP/1080p/720p @25/30fps
- CVBS Camera: PAL/NTSC
- IP Camera Input: 4+2ch, each channel up to 1080p
- Audio In/Out: 1ch input, 1ch output, RCA
- Two-way Talk: Support
Display
- Interface: 1 HDMI, 1 VGA, 1 CVBS
- Resolution: HDMI: 3840×2160, 1920×1080, 1440×900, 1280×1024
- VGA: 1920×1080, 1280×1024, 1280×720
- Multi-Screen Display: 1/4
Recording
- Resolution: 5MP, 4MP, 1080p, 720p, D1, CIF
- Record Rate: 5MP @6fps, 4MP @7fps, 1080p @15fps
- Bit Rate: Main Stream: 128Kbps~6144Kbps
- Sub Stream: 16Kbps~1024Kbps
- Record Mode: Manual, Event, Timer
- Record Interval: Post-record: 30 ~ 60 sec
Video Detection and Alarm
- Trigger Events: Recording, Buzzer, Push message, Popup Message
- Video Detection: Motion Detection, Video Loss, Camera Tamper
- Alarm in/out: N/A
Playback and Backup
- Playback: 4/1
- Search Mode: Time/Date, Alarm, Picture Grid, Event
- Playback Function: Play, Pause, Stop, Next Frame, Fast play, Slow Play, Layout, Shuffle, Backup Selection, Digital Zoom
- Backup Mode: USB HDD
Network
- Interface: 1 RJ-45 port (10/100Mbps)
- Network Function: HTTP, HTTPS, TCP/IP, IPv4, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP
- Max. User Acces:s: Access 4 Users
- Smart Phone: iPhone, iPad, Android
Storage
- Internal HDD: 1 SATA Ports, up to 8TB for each HDD
- eSATA: N/A
Interface
- USB Ports: 2× USB2.0
- RS232: N/A
- RS485: N/A
General
- Power Supply: DC12V 2A
- Power Consumption: Max. 5W (without HDD)
- Operating Temperature: -10 °C ~ 50 °C
- Storage Conditions: Less than 90% RH
- Certifications: CE/FCC
- Dimensions (L × W × H): 255 × 244 × 44mm
- Net Weight: 900g
Shipping Dimensions
- Weight: 1.10 kg
