| Camera |
| Image Sensor |
1/3” Progressive Scan CMOS |
| Effective Pixels |
2592(H)×1520(V) |
| Scanning System |
Progressive |
| Electronic Shutter |
1/5-1/20000s |
| Min. illumination |
Color:0.05Lux@(F1.2,AGC ON) ; |
| B/W:0Lux@(IR LED ON) |
| S/N Ratio |
55dB |
| IR Range |
Up to 30m |
| IR On/Off Control |
Auto/ Manual |
| IR LEDs |
15pcs |
| Pan/Tilt/Rotation Range |
Pan:0˚~355˚, Tilt:0˚~80˚, Rotation:0˚~355˚ |
| Lens |
| Lens Type |
Motorized |
| Iris |
Auto Iris |
| Focal Length |
2.7~12mm |
| F Number |
F1.3 |
| Angle of View |
100°~ 30° |
| Focus Control |
Motorized |
| Close Focus Distance |
0.2m |
| Video |
| Compression |
H.265,H.264,MJPEG |
| Max. Resolution |
4MP(2592×1520) |
| Streaming Capability |
3 Streams |
| Stream / |
Stream1: 2592×1520/2560×1440/2304×1296/ 1920×1080/1280×720 @25/30fps |
| Frame Rate |
Stream2: D1/VGA/640×360/CIF/QVGA @25/30fps |
| |
Stream3: VGA/CIF/QVGA @25/30fps |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
Stream1: 500kbps~12000kbps |
| Stream2: 100kbps~6000kbps |
| Stream3: 100kbps~3000kbps |
| Day/Night |
ICR |
| Image Enhancement |
HLC / Defog / WDR (120dB) |
| White Balance |
Support |
| Gain Control |
Auto/Manual |
| Noise Reduction |
2D/3D DNR |
| Electronic Image Stabilization(EIS) |
Support |
| Smart IR |
Support |
| Mirror |
Support |
| Region of Interest |
Support |
| Motion Detection |
Support |
| Privacy Masking |
Support |
| Audio |
| Compression |
G.711 ,RAW_PCM |
| Bit Rate |
64kbps (G.711), 128kps (RAW_PCM) |
| Network |
| Protocols: |
IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, APR, SNMP |
| Interoperability |
ONVIF |
| Streaming Method |
Unicast |
| Max. User Access |
10 Users |
| Web Viewer |
<IE11, Chrome, Firefox |
| Management Software |
IMS 3.0 |
| Smart Phone |
IOS, Android |
| Intelligence |
| IVS |
Perimeter ,Single Virtual Fences ,Double Virtual Fences ,Loiter ,Multi Loiter ,Object Left ,Object Removed, Abnormal Speed ,Converse, Illegal Parking , Signal Bad |
| Interface |
| Ethernet |
1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Audio Interface |
1ch Audio In,1ch Audio Out, 1ch Built-in Mic |
| Alarm |
1ch Alarm In, 1ch Alarm Out |
| RS485 |
Optional |
| BNC Output |
Support |
| Reset Button |
Support |
| Edge Storage |
Micro SD, Max 128GB |
| Electrical |
| Power Supply |
DC12V/POE |
| Power Consumption |
3.5W(IR LED OFF), 7W（IR LED ON） |
| Operating Temperature |
Starting Temperature: -30°C ~ 60°C (-22°F ~ 140°F ) |
| Working Temperature: -40°C ~ 60°C (-40°F ~ 140°F) |
| Operating Humidity |
Less than 90% RH |
| Ingress Protection |
IP67,IK10 |
| Certifications |
CE / FCC |
| Casing |
Metal |
| Dimensions |
φ139×117mm |
| Net Weight |
880g |
