HomeSiren Fibra White
Manufacturer overview
Wired siren with an LED connector
Smart wired siren on high alert. Superior HomeSiren Fibra is a wired indoor siren that responds to Ajax system alarms in less than a second. This device emits a sound of up to 105 dB , which is loud enough to deter intruders and alert an entire facility, even as large as a factory. The siren can also indicate exit/entry delays and inform users of alarms from any detector in the system. For example, it is possible to set up a sound signal when the door 1 is opened. Superior HomeSiren Fibra users with admin rights can remotely configure alarm types, volume levels, and other siren settings via Ajax apps for PROs.
One device, five missions. The siren emits an alarm signal in the event of a threat, such as a fire, water leakage, or intrusion. The loud sound will also help scare away an intruder. An installation engineer configures alarm types and the siren volume in Ajax PRO apps.
Informs of any alert. The siren emits an alarm signal in the event of a threat, such as a fire, water leakage, or intrusion. The loud sound will also help scare away an intruder. An installation engineer configures alarm types and the siren volume in Ajax PRO apps.
Indicates delays. Superior HomeSiren Fibra can be configured to signal the delay when entering or leaving. If the feature is enabled, the built-in or external LED indicator and sound remind a user that the site needs to be disarmed.
Displays the security mode. The siren can inform about a security mode change with sound and light indication. The LED indicator can also be always on to keep the siren’s state secret from outsiders.
Notifies of doors being opened. Superior HomeSiren Fibra provides the Chime feature. It allows the siren to play a specific sound when opening detectors are triggered while the system is disarmed. The feature is ideal for stores, as it instantly alerts employees when new visitors enter.
Specifications
| Line connection |
4-core cable |
| Fibra line length |
up to 6,500 ft |
| Alarm type |
acoustic and LED |
| Type of warning device |
internal |
| Alarm volume |
from 81 to 105 dB at a distance of 3.3 ft |
| Alarm duration |
from 3 s to 3 min |
| Siren sound frequency |
3.4 ± 0.5 kHz |
| Additional LED connection |
3 V |
| Protection against forgery |
device authentication |
| Siren’s operating voltage range |
7−26 V⎓, up to 1811 mW |
| Siren’s nominal operating voltage |
24 V⎓ |
| Maximum siren’s current consumption at nominal voltage |
75.5 mA |
| Quiescent siren’s current consumption at nominal voltage |
66 µA |
| Peak siren’s current consumption at nominal voltage |
77 mA |
| Average siren’s current consumption at nominal voltage |
65 µA |
| Protection class |
IP50, IK06 |
| Dimensions |
3.58″ × 3.58″ × 1.30″ |
| Weight of the black device |
3.35 oz |
| Weight of the white device |
3.81 oz |
| Operating temperature range |
from 14 °F to 104 °F |
| Operating humidity |
up to 75% |
| Warranty |
24 months |
