- Sound volume level: Adjustable, 81 - 105 dB at a distance of 1 m
- Alarm length: Adjustable, 3 - 180 sec
- Battery: 2 x CR123A batteries, 3 V
- Battery life: up to 5 years
- Up to 2000m in an open space (in a perfect environment)
- Protection class: IP50
- Certification: Grade 2, CE
- Dimensions: 75 × 76 × 27 mm
Manufacturer overview
Wireless siren with an LED connector
Loud and reliable. HomeSiren Jeweller is a smart indoor device that does more than alerting alarms. It can also serve as a security status indicator, notify of door openings, and display delays when entering or leaving and after-alarm. The device operates autonomously on pre-installed batteries for up to 5 years and uses wireless Jeweller radio protocol to communicate with a hub or range extender at a distance 1 of up to 6,500 ft . HomeSiren Jeweller is protected at hardware and software levels and easy to control via Ajax apps.
One device. Five missions. The siren deters intruders and notifies of fire detection, water leaks, and other alarms. An installer can set up the detector that triggers the sound and LED indication.
Informs about any alert. The siren deters intruders and notifies of fire detection, water leaks, and other alarms. An installer can set up the detector that triggers the sound and LED indication.
Indicates the delays. HomeSiren Jeweller can be set to indicate a delay when entering or leaving. If the feature is on, the built-in LED and sound remind a user that the system needs to be disarmed.
Displays a security mode. The siren’s LED indicator can turn on to show that the system is armed or that the security mode has changed or be always on to avoid unwanted tracking. Also, sound indication and third-party LEDs can be used.
Notifies of door opening. HomeSiren Jeweller can make a special sound to indicate that the opening detector’s sensors are triggered when the system is disarmed. It is a Chimes feature, and it is perfect for stores. Employees will immediately know about new visitors.
Specifications
| Frequency bands |
866.0–866.5 MHz |
| Maximum effective radiated power (ERP) |
up to 25 mW |
| Radio signal modulation |
GFSK |
| Radio communication range |
up to 6,500 ft |
| Alarm type |
acoustic and LED indication |
| Warning device type |
type W |
| Alarm volume |
from 80 to 100 dB at a distance of 3.3 ft |
| Alarm duration |
from 3 s to 3 min |
| Siren sound frequency |
3.4 ± 0.5 kHz |
| Ability to connect an additional LED |
3 V⎓ |
| Protection against spoofing |
device authentication |
| Communication loss detection |
after 36 s |
| Battery |
2 × CR123A |
| Calculated battery life |
up to 5 years |
| Siren’s operating voltage range |
1.9−3.3 V⎓ |
| Siren’s nominal operating voltage |
3 V⎓ |
| Quiescent siren’s current consumption at nominal voltage |
68 µA |
| Peak siren’s current consumption at nominal voltage |
1.1 A |
| Average siren’s current consumption at nominal voltage |
50 mA |
| Full battery capacity |
3,200 mAh |
| Low battery voltage |
2.1 V⎓ |
| End-of-life battery voltage |
1.9 V⎓ |
| End-of-life battery capacity |
366 mAh |
| Manufacturer |
Huiderui |
| Protection class |
IP50 |
