Features
- Extends USB KVM control up to 150m over quality CAT5e cable
- Two users can share one or two computers locally or remotely
- Sharp video support up to 1600 × 1200 @50m and 1024 × 768 @150m
- Ideal for secure, industrial and space-saving installations
- Simple, reliable, plug-and-play operation
Specifications
Extension and Connectivity
- Transmission Medium: Standard CAT5e Cable
- Maximum Extension Distance: up to 150m
- Local Console Connection: USB Keyboard a Mouse + VGA Video
- Remote Console Connection: USB Keyboard & Mouse + VGA Video
- Local PC Connection: USB + VGA Ports
- Remote PC Connection: CAT5e Port for Extender Link
Video Support
- Resolution @50m: up to 1600 × 1200
- Resolution @150m: up to 1024 × 768
- Video Connector Type: VGA
USB and Peripheral Support
- Keyboard / Mouse Interface: USB Human Interface Device (HID)
- USB Ports: Local unit - USB Ports for Keyboard & Mouse, Remote Unit - USB Console Ports
Power
- Power Input: External DC 9V Adapter
- Power Connector: Standard Barrel Connector
Indicators and Controls
- Status LEDs: Local / Remote / PC Activity Indicators
- Console Mode: Local / Remote Selection Buttons or Switch
Environmental and Physical
- Operating Temperature Range: Typical Commercial Grade (0~40°C)
- Storage Temperature: Model Dependent
- Housing: Metal Enclosure
- Mounting: Desktop or Rack Shelf Installation
Compatibility
- USB Standards: USB-HID Compatible Keyboards & Mice Supported
- Operating Systems: Works with Standard PC Environments that Support USB HID
- Keyboard / Mouse Protocol: No Proprietary Drivers Required
Dimensions (H × W × D): 20 × 156 × 65mm
Shipping Dimensions
- Length: 35.5 cm
- Width: 29.4 cm
- Height: 19.7 cm
- Weight: 2.60 kg
