Description
Features
- Compact, 1U Design - Space-saving form factor ideal for dense rack installations
- Secure Dedicated Cabling - Uses unique cables for reliable and protected connections
- Auto-Scan Function - Automatically cycles through connected computers sequentially
- Custom Computer Naming - Assigns meaningful names to each connected system
- Name-Based Computer Selection - Quickly identify and select computers by name
- Programmable Scan Filters - Skips unused computers during auto-scan operation
- Nonvolatile Memory Storage - Retains system settings and name entries after power loss
- Password Security Protection - Prevents unauthorised access to connected computers
- User-Friendly OSD Interface - Provides complete control through an easy, on-screen display
- Hotkey Switching Support - Enables fast keyboard-based computer access
- OS-Independent Operation - Transparent to operating systems and applications
- Plug-and-Play Configuration - No software or drivers required
- High Resolution Support - Supports VGA resolutions up to 1920×1440
- DDC2B Compatibility - Ensures accurate monitor communication
- SUN Keyboard Emulation - Supports SUN keyboard environments for broader compatibility
Specifications
- Control Buttons on Front Panel: 4×
- Applicable Computers: USB PC, USB Sun, USB Mac
- On-Screen Display (OSD): Yes
- Plug-and-Play: Yes
- Hotkey Control: Yes
- Computer Name Entry: 14-Characters
- Auto-Scan Interval: 3, 8, 15, 30 Seconds
- Programmable Scan Pattern: Yes
- Security Control: 4-Character Password per Computer
- Cable Type: 1-to-2 USB Cable, Max. 5m
- Video Resolution: 1920×1440, DDC2B
- Computer Connectors: 4× VGA (Grey) + USB Interface
- Console Connectors: 1× USB Mouse, 1× USB Keyboard, 1× VGA Monitor Female
- Power Consumption (Max.): 9V DC, 500mA
- Dimensions (H × W × D): 44 × 220 × 130mm
Shipping Dimensions
- Length: 35.5 cm
- Width: 29.4 cm
- Height: 19.7 cm
- Weight: 3.40 kg
