Rextron KNVM-08A2 8-Port 4K @30Hz HDMI KVM Switch with Mouse Control and Broadcast Mode
Centralised Control. Seamless Switching. True 4K Performance.
The Rextron KNVM-08A2 is a professional-grade 8-port HDMI KVM switch designed to manage multiple systems from a single console with precision and efficiency. Supporting resolutions up to 4K (3840 × 2160 @30Hz), it delivers clear and reliable video output for demanding environments such as control rooms, broadcast systems and server management. With advanced mouse control and broadcast mode, users can seamlessly switch between systems or execute commands across multiple computers simultaneously, significantly improving workflow efficiency. Flexible control options including front panel buttons, hotkeys and mouse switching ensure intuitive operation across various applications.
Features
- 8-Port HDMI KVM Switch - Control up to 8 computers from a single console
- 4K UHD Resolution - Supports up to 3840 × 2160 @30Hz
- Mouse Control Switching - Easily switch between systems using mouse buttons and scroll wheel
- Broadcast Mode - Send commands simultaneously to all connected systems
- Multiple Control Methods - Front panel push buttons, hotkey commands and mouse control
- HDCP Support - Ensures smooth and uninterrupted video playback
- EDID Management - Copy and auto-learning EDID for optimal display compatibility
- USB HID Support - Enables keyboard and mouse hot-swapping
- Cross-Platform Compatibility - Supports Windows and Mac systems
Specifications
Video
- Video Resolution (Max.): 4K (3840 × 2160) @30Hz
- HDCP Compliant: Yes
- EDID Function: Copy and Auto Learning
Pc Interface
- Video Input: 8× HDMI
- USB Interface: 8× USB Type-B
Console Interface
- Video Output: 1× HDMI
- USB Interface: 4× USB Type-A
Control And Indicators
- Status LED: 1× LED
- Port LED: 8× PC Ready (Green), 8× Port Selected (Red)
- Push Button: 8× Port Select, 1× EDID Copy (Rear)
- Control Methods: Push Button, Hotkey Control, Mouse Control Mode
General
- Enclosure: Metal
- Power Supply: DC 12V
- Dimensions (H × W × D): 44 × 436 × 180mm
