Rextron EUC-222C USB KVM Extender over CAT5e up to 150m
Extend control. Eliminate distance.
The Rextron EUC-222C USB KVM Extender lets you control your computer from up to 150 metres away over standard CAT5e cable - perfect for secure rooms, server environments, factories and control centres. Share one or two computers between local and remote users with smooth video performance and reliable USB keyboard and mouse support.
Big distance. Clean signal. Total control.
Features
- Extends USB KVM control up to 150m over quality CAT5e cable
- Two users can share one or two computers locally or remotely
- Sharp video support up to 1600 × 1200 @50m and 1024 × 768 @150m
- Ideal for secure, industrial and space-saving installations
- Simple, reliable, plug-and-play operation
Specifications
Extension and Connectivity
- Transmission Medium: Standard CAT5e Cable
- Maximum Extension Distance: up to 150m
- Local Console Connection: USB Keyboard a Mouse + VGA Video
- Remote Console Connection: USB Keyboard & Mouse + VGA Video
- Local PC Connection: USB + VGA Ports
- Remote PC Connection: CAT5e Port for Extender Link
Video Support
- Resolution @50m: up to 1600 × 1200
- Resolution @150m: up to 1024 × 768
- Video Connector Type: VGA
USB and Peripheral Support
- Keyboard / Mouse Interface: USB Human Interface Device (HID)
- USB Ports: Local unit - USB Ports for Keyboard & Mouse, Remote Unit - USB Console Ports
Power
- Power Input: External DC 9V Adapter
- Power Connector: Standard Barrel Connector
Indicators and Controls
- Status LEDs: Local / Remote / PC Activity Indicators
- Console Mode: Local / Remote Selection Buttons or Switch
Environmental and Physical
- Operating Temperature Range: Typical Commercial Grade (0~40°C)
- Storage Temperature: Model Dependent
- Housing: Metal Enclosure
- Mounting: Desktop or Rack Shelf Installation
Compatibility
- USB Standards: USB-HID Compatible Keyboards & Mice Supported
- Operating Systems: Works with Standard PC Environments that Support USB HID
- Keyboard / Mouse Protocol: No Proprietary Drivers Required
Dimensions (H × W × D): 20 × 156 × 65mm
