Shuttle DS50U3 XPC slim Fanless Barebone PC with Intel i3 1315U CPU
Compact Power. Triple Display Performance.
Built for demanding environments, the Shuttle DS50U3 delivers reliable, fanless computing in a slim, industrial-grade chassis. Supporting independent triple display output via HDMI, DisplayPort and VGA, it is ideal for digital signage, control rooms and multi-screen deployments. Designed for silent, maintenance-free operation, it combines flexible connectivity, energy efficiency and robust stability for continuous 24/7 use in space-constrained environments.
Features
- Fanless Design - Silent, maintenance-free operation for 24/7 reliability
- Triple Display Output - HDMI, DisplayPort and VGA with independent output
- Intel Processor Platform - Efficient performance for industrial applications
- Slim Industrial Chassis - Compact design ideal for space-constrained deployments
- Dual LAN Ports - Reliable network redundancy and flexible connectivity
- 4× USB3.2 Ports - High-speed peripheral connectivity
- Wide Voltage Input - Supports 12~19V DC for industrial environments
- Dual Storage Support - 2.5" SATA plus M.2 SSD for flexible storage expansion
- VESA Mount Compatible - Easy installation behind displays or in enclosures
Specifications
- Processor: Intel Core i3-1315U (13th Gen, 6 Cores)
- Graphics: Intel UHD Graphics (Triple Display Support)
- Display Outputs: 1× HDMI, 1× DisplayPort, 1× VGA (Independent)
- Memory: 2× DDR5 SO-DIMM (up to 64GB)
- Storage:
- 1× 2.5" Sata
- 2× M.2 SSD (NVMe / SATA)
- Networking: Dual LAN (2.5GbE + 1GbE)
- Wireless Expansion: M.2 slot for Wi-Fi / Bluetooth Module
- USB Ports: 4× USB3.2 + 4× USB2.0
- Serial Ports: 2× COM (RS232/422/485)
- Audio: Line-in / Line-out (3.5mm)
- Video Resolution: up to 4K @60Hz (HDMI / DisplayPort)
- Power Input: 12~19V DC
- Power Consumption: up to 90W (Adapter)
- Cooling: Fanless Passive Cooling
- Mounting: VESA Mount Compatible
- Operating System: Windows 10 / 11, Linux
- Operating Temperature: 0~40°C
- Chassis: Metal Industrial Design
- Dimensions: 200 × 165 × 39.5mm
- Weight: 1.6kg
