| Power Supply |
100-240 VAC, 50/60 Hz |
| Power Consumption |
17 W |
| MAC Address Table |
8 K |
| Ports |
24 × 1 Gigabit PoE port,4 × 1 Gigabit combo |
| Switching Capacity |
Whole-Device Performance: 336 Gbps Port Performance: 336 Gbps |
| Packet Forwarding Rate |
Whole-Device Performance: 51 Mpps Port Performance: 51 Mpps |
| VLAN |
Support IEEE 802.1Q (VLAN), 4096 VLAN IDs Support GVRP Support QinQ Support VLAN based on MAC/protocol/IP subnet/policy/port Support Private VLAN Support 1:1 and N:1 VLAN mapping functions |
| QoS |
Support Diff-Serv QoS Support 802.1p/DSCP priority mapping Support queue scheduling including SP, WRR, WFQ, SP+WRR, SP+WFQ Support priority marking and remarking Support traffic shaping Support congestion avoidance, Tail-Drop and WRED Support 802.1p, TOS, DSCP, and EXP priority mapping Support port/flow-based rate limiting |
| Management Method |
Support Console, Telnet, SSH Support web, http, https Support FTP, TFTP, Xmodem, SFTP Support SNMP V1/V2c/V3 Support RMON Support NTP |
| Multicast |
Support IGMP v1/v2/v3 Snooping Support IGMP V1/V2/V3 Support MLD Snooping v1/v2 Support MLD v1/v2 |
| Security |
Support AAA,TACACS+ Radius authentication Support 802.1X authentication, MAC authentication, MAC bypass authentication Support to prevent DOS, ARP attack function, ICMP anti attack Support binding of IP, MAC, port and VLAN Support MAC authentication Support MAC address filtering Support broadcast/multicast/unknown-unicast storm control |
| PoE Standard |
IEEE 802.3af,IEEE 802.3at |
| PoE Power Pin |
1/2 (+), 3/6 (-) |
| PoE Power Budget |
370 W |
| EMC |
FCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 24) |
| Safety |
UL (UL 62368-1); CB/RCM (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2034) |
| Chemistry |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2023) |
| Net Weight |
3.1 kg (6.83 lb) |
| Dimensions (W × H × D) |
440.00 mm × 44.00 mm × 210.00 mm (17.32'' × 1.73'' × 8.27'') |
| Operating Temperature |
-10 °C to 50 °C (14 °F to 122 °F) |
| Operating Humidity |
10% to 90% (no condensation) |
