TP-Link | Omada SG3452XP 8-Port Gigabit and 4-Port 10GE SFP+ L2+ Managed Switch with 48-Port PoE+
The TP-Link Omada SG3452XP is a 48-port Gigabit L2+ managed switch with PoE+ support and 10G SFP+ uplinks, designed for high-capacity enterprise access deployments. Fully integrated into the Omada SDN platform, it delivers advanced routing, high-speed aggregation, and powerful PoE for large-scale Wi-Fi and IP surveillance environments.
Features
- 48 × 10/100/1000Mbps RJ45 ports
- 48 × PoE+ ports (802.3af/at compliant)
- 4 × 10G SFP+ uplink ports
- Up to 30W per PoE+ port
- 500W total PoE power budget
- L2+ features including static routing
- Integrated into Omada SDN platform
- Advanced VLAN, QoS and ACL support
- Intelligent PoE power management
- Rackmount enterprise chassis
Specifications
- Ports: 48 × 10/100/1000Mbps RJ45 PoE+ ports
- Uplink Ports: 4 × 10G SFP+ slots
- PoE Standard: 802.3af/at PoE+
- Max Power per Port: 30W
- Total PoE Budget: 500W
- Switching Capacity: 176Gbps
- Forwarding Rate: 130.9Mpps
- MAC Address Table: 16K entries
- Management: Omada SDN (Cloud / Hardware Controller / Software Controller / Standalone Web)
- Features: L2+ static routing, VLAN, QoS, ACL, IGMP Snooping
- Installation: Rackmount
- Power Supply: Internal power supply
