TP-Link TL-SG1008D 8-Port Gigabit Desktop Switch
The TL?SG1008D is an unmanaged Gigabit Ethernet switch in a desktop (or wall-mountable) form factor. It痴 designed to expand your wired network by providing 8 RJ?45 ports that support 10/100/1000 Mbps, while maintaining simplicity (no configuration required).
Features
- 8 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
- Green Ethernet technology saves the power up to 80%
- IEEE 802.3x flow control provides reliable data transfer
- Plastic case, desktop or wall-mounting design
- Plug and play, no configuration required
Specifications
Hardware Features
- Standards and Protocols: IEEE 802.3i/802.3u/ 802.3ab/802.3x
- Interface: 8 10/100/1000Mbps RJ45 Ports
- AUTO Negotiation/AUTO MDI/MDIX
- Fan Quantity: Fanless
- Physical Security Lock: No
- External Power Supply: External Power Adapter (Output: 9VDC/0.6A)
- Jumbo Frame: 15 KB
- Switching Capacity: 16 Gbps
- Dimensions (WxDxH) 180 x 90 x 25.5mm
- Max Power Consumption: 4.63W(220V/50Hz)
- Max Heat Dissipation: 15.80BTU/h
Software Features
- Transfer Method: Store and Forward
- MAC Address Table: 4K
- Advanced Functions: Green Technology
- 802.3X Flow Control
- Back Pressure
- 802.1p/DSCP QoS (for V7 and later version)
Others
- Certification: FCC, CE, RoHs
