TP-Link TL-SG1005D 5-Port Gigabit Desktop Switch
The TL?SG1005D is an unmanaged Gigabit Ethernet switch for desktop or wall?mount use. It gives you five RJ?45 ports that support 10/100/1000 Mbps speeds, so good for upgrading from 100 Mbps networks or expanding on devices needing Gigabit links. Because it's unmanaged, there's no setup/config - just plug and play.
It also includes 敵reen Ethernet" features to reduce power usage under certain conditions, making it more efficient.
Features
- 5 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
- Green Ethernet technology saves power consumption
- IEEE 802.3x flow control provides reliable data transfer
- Plastic case, desktop or wall-mounting design
- Plug and play, no configuration required
Specifications
Hardware Features
- Interface: 5 10/100/1000Mbps RJ45 Ports
- AUTO Negotiation/AUTO MDI/MDIX
- Fan Quantity: Fanless
- Physical Security Lock: No
- External Power Supply: External Power Adapter (Output: 5VDC / 0.6A)
- Dimensions: 140 × 88 × 23mm
- Max Power Consumption: 3.1W (220V/50Hz)
- Max Heat Dissipation: 10.57 Btu/hr
Software Features
- Transmission Method: Store and Forward
- Advanced Functions: Green Technology
- 802.3x Flow Control
- Back Pressure
- 802.1p/DSCP QoS (for V7 and later version)
Others
- Certification: FCC, CE, RoHs
