ProsKit MT-7616 4-in-1 Fibre Optical Power Multimeter, including Power Meter, LAN Cable Tester, Visual Fault Locator and LED Flashlight
A versatile all-in-one testing solution for fibre and network professionals. The ProsKit MT-7616 combines a fibre optical power meter a LAN cable tester a visual fault locator and an LED flashlight into a single compact tool. Designed for fast diagnostics and field efficiency it enables accurate fibre testing cable verification and fault identification making it ideal for installers and technicians working across fibre and copper network environments.
Features
- 4-in-1 Design with 30mW Output - Combines multiple fibre and network test functions in one tool
- Self-Calibration - Ensures accurate measurements without manual adjustment
- Rechargeable Li-ion Battery - A 450mAh battery provides reliable portable power for field work
- 500× Data Storage Groups - Stores test results for easy review and reporting
- Integrated Cable Tester - Verifies LAN cable continuity and performance
Specifications
- Detector Type: InGaAs
- Wavelength Response Range: 700~1700nm
- OPM Connector: 2.5mm Universal Connector
- Measurement Wavelengths: 850nm, 980nm, 1300nm, 1310nm, 1490nm, 1550nm, 1625nm, 1650nm
- Measurement Range: -70~+10dB
- Resolution: 0.01dB
- Accuracy (1550nm and 1310nm): 0.2dB
- Accuracy (1490nm, 1625nm and 1650nm): 0.3dB
- Accuracy (850nm, 980nm and 1300nm): 0.4dB
- Measurement Units: dB, dBm, mW, uW, nW
- Modulation Detection: 270Hz, 1kHz, 2kHz
- Data Storage: 500× Groups
- Wavelength Memory: Yes
- WAVE ID: Yes (only for ProsKit light source products)
- User Self-Calibration: Yes
- REF Function: Yes
- Back Light: Yes
- Output Power: 30mW
- Fibre Testing Distance: 14~16km @SM
- VFL Connector: 2.5mm Universal Connector
- VFL Wavelength: 650 ±20nm
- Operation Mode: CW / 2Hz Glint
- Network Application: UTP Network Cable
- Interface: RJ45 (UTP 8P8C)
- Network Testing Type: Network Sequence
- Network Testing Distance: 600m
- Illumination: LED
- Auto Power-Off: Yes (no operation for 10 minutes)
- Low Battery Indicator: Yes
- Charging Socket: Micro USB
- Working Time: >50hours (OPM only)
- Power Source: 3.7V 450mAh Li-ion
- Operating Temperature: -10~50°C
- Operating Humidity: <90% RH
- Dimensions (L × W × H): 98 × 59 × 27mm
- Weight: 100g
