Mercusys ME20 AC750 Wi-Fi Range Extender
Expand Your Wi-Fi Coverage with Reliable Dual-Band Performance.
The Mercusys ME20 AC750 Wi-Fi Range Extender helps eliminate weak signal areas by extending your existing wireless network to more parts of your home or office. With combined dual-band speeds of up to 750Mbps, it delivers stable connectivity for browsing, streaming and everyday online activities. The simple Plug-and-Play setup with WPS pairing makes installation quick and effortless, while the multicolour signal indicator helps you position the extender for optimal Wi-Fi coverage.
Features
- Eliminate Wi-Fi Dead Zones - Boosts Wi-Fi signals to previously unreachable or hard-to-wire areas flawlessly
- AC750 Dual Band Wi-Fi - Keep your whole home connected with strong Wi-Fi expansion at a combined speed of up to 750Mbps
- Easy One-Touch Setup - Simply press the WPS button to expand your Wi-Fi coverage in seconds
- Signal Indicator - Multicolour LED helps you find the right location for your range extender for the best Wi-Fi extension
- Fast 10/100Mbps Port - Provides speedy wired connections for PCs, IPTVs and game consoles
Specifications
Hardware
- Port: 1× 10/100Mbps RJ45 Port
- Button: Reset / WPS Button
- Power Consumption: 7.2W
- Dimensions (W × D × H): 112 × 84.7 × 39mm
Wireless
- Wireless Standards: IEEE 802.11n/ac (5.0GHz), IEEE 802.11b/g/n (2.4GHz)
- Frequency: 2.4~2.5GHz, 5.0GHz
- Signal Rate: Up to 750Mbps
- 433Mbps on 5.0GHz
- 300Mbps on 2.4GHz
Eirp
- 2.4GHz: ≤20dBm
- 5.0GHz: Band 1 ≤23dBm, Band 3 ≤30dBm
Reception Sensitivity
11ac VHT80 MCS9: <-63dBm
11n HT40 MCS7: <-71dBm
Wireless Security
Certification
