Features
- Maximum coverage – four 5dBi antennas provide up to 500m2 of wireless coverage
- Enhanced signal – high gain antennas dramatically increase wireless signal strength, size and stability
- 300Mbps wireless speed - ideal for HD streaming, online gaming, and large file downloads
- Easy installation - intuitive webpage guides you through the setup process in minutes
*Range specifications are based on performance test results. Real performance varies in accordance with applications and environmental conditions
Specifications
- External Power Supply: 5VDC/0.6A
- Antenna Type: 4 x 5dBi fixed omni directional antennas
- Signal Rate11n: Up to 300Mbps (Dynamic)
- 11g: Up to 54Mbps (Dynamic)
- 11b: Up to 11Mbps (Dynamic)
- Button: Reset button
- Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
- Frequency: 2.4 - 2.5GHz
- Reception Sensitivity:
- 270M: -70dBm@10% PER
- 130M: -72dBm@10% PER
- 54M: -74dBm@10% PER
- 11M: -87dBm@10% PER
- 6M: -92dBm@10% PER
- 1M: -94dBm@10% PER
- Interfaces: 3 10/100Mbps LAN ports, 1 10/100Mbps WAN port
- Certifications: CE, ROHS
Shipping Dimensions
- Length: 31.2 cm
- Width: 24.6 cm
- Height: 6.6 cm
- Weight: 0.53 kg
