DoorProtect Plus Fibra White
Manufacturer overview
Wired reed-switch opening detector with shock and tilt sensors
Guardian for doors, windows, and valuables. Superior DoorProtect Plus Fibra is designed to detect intrusion and burglary attempts, offering comprehensive coverage for doors, windows, skylights, and vaults. The detector, equipped with two reed switches as opening sensors, features protection against chattering in its operation. Two sizes of magnets provide more mounting options. The device also identifies shock and tilt with a built-in accelerometer, protecting the facility even when windows are in airing mode. All in line with the Ajax user experience, ensuring quick and easy installation of the device.
No intruder goes unnoticed. Superior DoorProtect Plus Fibra features two durable reed switches, guaranteeing decades of trouble-free operation. Two reed switches allow the magnet to be positioned on either side of the sensor (right or left). Housed in resilient plastic capsules, these switches remain intact even in cases of drops or transportation, ensuring the detector’s effective functionality irrespective of magnet placement.
High-end reed switches for reliable opening detection. Superior DoorProtect Plus Fibra features two durable reed switches, guaranteeing decades of trouble-free operation. Two reed switches allow the magnet to be positioned on either side of the sensor (right or left). Housed in resilient plastic capsules, these switches remain intact even in cases of drops or transportation, ensuring the detector’s effective functionality irrespective of magnet placement.
Immediate detection of threats. The built-in accelerometer responds swiftly to shocks, detecting potential burglary attempts such as door forcing and vault breaking. The shock sensor has three levels of sensitivity, which can be adjusted to match the secured facility specifics. The detector can also ignore a single impact to minimize the risk of false alarms triggered by external factors. Whether there are vibrations from neighboring constructions or heavy passing traffic, the installer can choose the most appropriate settings for accurate detection.
Windows protection in an airing mode. The built-in accelerometer is designed to protect open windows, seamlessly adapting to diverse facility requirements. Installers can select a normal tilt angle for doors or windows, ranging from 5 to 25 degrees. The system swiftly detects even the slightest deviations from the usual position and provides customizable tilt detection durations, ranging from 1 second to 1 minute. In case the tilt angle surpasses the specified threshold for an extended period, the system raises an alarm.
Unique wired technology. Fibra is proprietary Ajax technology for secure two-way communication between devices and a hub or module that extends the Fibra line. Fibra features encryption and device authentication to prevent sabotage, spoofing, and data theft. The Fibra line supports all types of devices, including sirens, keypads, and detectors with photo verification.
Specifications
| Line connection |
4-core cable |
| Fibra line length |
up to 6,500 ft |
| Sensing element |
1 × accelerometer |
| Shock sensor sensitivity |
3 levels |
| Tilt sensor activation threshold |
from 5° to 25° |
| Protection against forgery |
Device authentication |
| Detector’s operating voltage range |
5−30 V⎓, up to 147 mW |
| Detector’s nominal operating voltage |
24 V⎓ |
| Quiescent detector’s current consumption at nominal voltage |
0.043 mA |
| Maximum detector’s current consumption at nominal voltage |
6.1 mA |
| Protection class |
IP50, IK04 |
| Dimensions |
3.56″ × 0.83″ × 0.73″ |
| Weight of the white device |
0.6 oz |
| Weight of the black device |
0.53 oz |
| Operating temperature range |
from 14 °F to 104 °F |
| Operating humidity |
up to 75% |
| Warranty |
24 months |
