Name: INTERCOM Video Master Station DS-KM9503
Brand: Regal
SKU: LK451-8
Price: 14623.42 ZAR
Availability: InStock

Roll over image to zoom in Click on image to zoom

10 inch Touch Android IP Main Station

10.1-inch IPS touch screen with 1280 × 800 resolution
Built-in SIP private server, up to 10,000 video intercom devices accessesUp to 128 network cameras can be added to the device
Supports more than 2 speakers and microphones: Connects to external earphone (3.5 mm), external goose neck microphone
Displays operation pages via HDMI
Supports standard PoE & 12 VDC power supply
Video intercom and access control functions: Call waiting, call priority configuration, call across buildings, call forwarding (call forward when no answer, call forward when busy, call forwarding schedule, one-touch call forwarding), IPC fowarding，Multi-party intercom

Operation system	Android 7.1
ROM	8 GB
RAM	2 GB
Processor	Embeded high performance processor
Screen size	10.1-inch
Operation method	Capacitive touch screen
Type	Colorful IPS
Resolution	1280 × 800
Lens	/
FOV	Horizontal: 64.1°, Vertical: 48.1°, Diagonal: 80.2°
Wide dynamic range (WDR)	/
Supplement light	/
Video compression standard	Main stream: H.264; Sub-stream: H.264
Audio input	Built-in omnidirectional microphone, external speaker, external goose neck microphone, external earphone (3.5 mm)
Audio compression standard	G.711 U、G.711 A、Opus、AAC-LD、AAC-LC、G.726、G.722.1
Audio output	Built-in loudspeaker, external speaker, external voice box or earphone (3.5 mm)
Audio compression bitrate	64 Kbps
Audio quality	Noise suppression and echo cancellation
Volume adjustment	Adjustable
Linked network camera capacity	128
Linked intercom device capacity	10,000
Network protocol	TCP/IP, SIP, RTSP
Wi-Fi	/
3G/4G	/
Zigbee	/

INTERCOM Video Master Station DS-KM9503

Description
