Features
- Professional choice USB3.2 Gen1 Type-A to Micro-B cable for commercial and high performance AV and IT installations
- SuperSpeed USB - Supports data transfer speeds up to 5Gbps
- Robust PVC housing, gold plated connectors and contacts
- Triple shielded cable, corrosion resistant tinned copper conductors
Connectors
- Connector A: USB3.2 Type-A Male
- Connector B: USB3.2 Micro-B Male
- Housing Material: PVC
- Connector Plating: Gold
- Pin Construction: Brass
- Pin Plating: Gold
- Dimensions (Approx.) W × D × H:
USB Type-A: 15.5 × 35 × 7.8mm
Micro-B: 15.8 × 26 × 7.8mm
Cable Construction
- Colour: Black
- Jacket Diameter: 5.5mm
- Jacket Material: PVC
- Conductor Material: Tinned Copper
- Conductor Gauge Power: 24AWG
- Conductor Gauge Data: 28AWG
- Shielding: 80% Aluminium-Magnesium Braid
Specifications
- Nominal Attenuation: 0.5MHz~7.5GHz <25dB
- Minimum Bend Radius: 48mm
- Operating Temperature: 0~40°C
- Storage Temperature: 0~70°C
- Product Compliance: RoHS, REACH, California Proposition 65 & UL
Shipping Dimensions
- Length: 20 cm
- Width: 20 cm
- Height: 2 cm
- Weight: 0.50 kg
