Features
- Professional choice High Speed HDMI cable for commercial and high performance AV and IT installations
- Supports UHD resolutions up to 4096x2160@60Hz and HDTV resolutions up to 1080p
- Robust PVC housing, 24K gold plated connectors and contacts
- Triple shielded cable, corrosion resistant tinned copper 28AWG conductors
- HDMI compliant: 3D, 4K, 18Gbps, HEC, ARC, CEC, Dolby True HD, DTS-HD Master Audio; HDMI ATC certified
- 10 year warranty
Connectors
Connector A: HDMI Type A Male
Connector B: HDMI Type A Male
Housing Material: PVC
Connector Plating: 24K Gold 3µm
Pin Construction: Phosphor Copper
Pin Plating: 24K Gold 3µm
Dimensions (approx.) WxDxH: 20 x 34.2 x 10.9mm
Cable Construction
- Length: 3m
- Standard: High Speed HDMI with Ethernet
- Colour: Black
- Type: Round
- Jacket Diameter: 7.3mm
- Jacket Material: PVC
- Conductor Material: Copper
- Conductor Gauge: 28AWG
- Shielding: Copper Braid, 65%
Specifications
- Supported Bandwidth: 18Gbps
- Maximum Resolution: 4096 x 2160 @60Hz 4:4:4 8bit
- Nominal Attenuation: 300kHz-825MHz <5dB,
825MHz-2.475GHz <5dB, 2.475GHz-4.125GHz <12dB, 4.125GHz-5.1GHz <20dB
- Minumum Band Radius: 48mm
- Operating Temperature: -30°C - 80°C
- Storage Temperature: -10°C - 85°C
- ATC Approved: Yes
Shipping Dimensions
- Length: 23.6 cm
- Width: 2 cm
- Height: 25.9 cm
- Weight: 0.19 kg
