Features
- Entry level High Speed HDMI cable for home and small office applications
- Supports UHD resolutions up to 4096x2160 @60Hz 4:4:4 8bit
- Robust PVC housing, nickel connectors, 24K gold plated contacts
- Triple shielded cable, corrosion resistant copper coated steel 30AWG conductors
- 10 year warranty
Connectors
- Connector A: HDMI Type A Male
- Connector B: HDMI Type A Male
- Housing Material: PVC
- Connector Plating: Nickel
- Pin Construction: Phosphor Bronze
- Pin Plating: Gold Flash
- Dimensions (approx.) WxDxH: 19.2x34.1x10.6mm
Cable Construction
- Length: 0.5m
- Standard: High Speed HDMI with Ethernet
- Colour: Black
- Type: Round
- Jacket Diameter: 5.5mm
- Jacket Material: PVC
- Conductor Material: Copper Coated Steel
- Conductor Gauge: 30AWG
- Shielding: Aluminium Foil
Specifications
- Supported Bandwidth: 18Gbps
- Maximum Resolution: 4096x2160@60Hz 4:4:4 8bit
- Nominal Attenuation: 300kHz-825MHz <5dB,
825MHz-2.475GHz <5dB, 2.475GHz-4.125GHz <12dB, 4.125GHz-5.1GHz <20dB
- Minumum Band Radius: 22mm
- Operating Temperature: -10°C - 80°C
- Storage Temperature: -30°C - 85°C
- ATC Approved: No
Shipping Dimensions
- Length: 0.5 cm
- Width: 17 cm
- Height: 1 cm
- Weight: 0.05 kg
