Features
- Built on ipcolor STREAM technology to deliver high-definition and low-latency transmission
- Supports up to 3840×2160 @60Hz resolution, backwards compatible
- Compatible with CAT5e/6 or higher-level networking cables, transmission distance of CAT6 cable is 120m
- Supports One-to-One or Many-to-Many connections through a Gigabit switch
- Supports RS232 passthrough and control
- The transmitter supports HDMI loop out
- Supports bi-directional IR pass-back (20~60KHz)
- Supports IR learning remote and control device by App
- Supports I/O interface control
- Supports POE (Power over Ethernet)
- Creating multi-screen splicing with up to 5x5 (also includes: 1x1/1x2/1x3/1x4/1x5/2x1/2x2/2x3/2x4/2x5/3x1/3x2/3x3/3x4/3x5/4x1/4x2/4x3/4x4/4x5/5x1/5x2/5x3/5x4/5x5) video wall through switch and controlled by App
- Supports 256 signal source inputs and 256 signal outputs, providing flexible Many-to-Many matrix configuration (requires App control operation while connecting more than 100 TX-to-RXs)
- Firmware upgrading via Micro USB port
- Lightning protection, surge protection, ESD protection
- Supports stable 24/7 operation
Specifications
- HDMI Length: ≤5m
- Maximum Transfer Rate: 18Gbps
- Compatibility: HDMI 2.0，HDCP 1.4 / HDCP 2.2
- Resolutions: 4096×2160 @24/30Hz, 3840×2160 @24/30/50/60Hz, 1080p @50/60Hz,720p @50/60Hz, 1920×1200 @60Hz, 2560×1440 @60Hz
- Connection Types:
One-to-One
Many-to-Many
Switch Cascading
- Transmission Distance: CAT5 80m / CAT5e 100m / CAT6 120m
- Transmission Latency:
4K @60Hz (130~200ms)
1080p @60Hz (70~130ms)
- HDMI Output: LPCM 2.0
- IR Receiving Range: ≤5m
- IR Frequency: 20kHz~60kHz
- RS232 (GND/RXD/TXD): Default Baud Rate:
115200
Supported: 2400, 4800, 9600, 19200, 38400, 57600, 115200
- Power Supply: TX/RX: DC 5V 2A (Alternative)
- Power Consumption:
Tx ≤5.5W
Rx ≤3.5W
- Working Temperature: -20~60°C
- Storage Temperature: -30~70°C
- Humidity: 0~90% RH (No Condensation）
- Housing: Metal
- Weight:
TX：523g
RX：514g
- Colour: Black
- Dimensions (L × W × H): 191 × 96 × 25mm
- Protection:
ESD Protection
1a Contact Discharge Level 2 (±4KV)
1b Air Discharge Level 3 (±8KV)
Implementation of the Standard: IEC61000-4-2
Lightning Protection, Surge Protection
Shipping Dimensions
- Length: 24 cm
- Width: 17.6 cm
- Height: 8 cm
- Weight: 0.88 kg
