Features
- 1× HDMI Source to 4× HDMI Displays
- 1080p @60Hz and 1920 × 1200
- Multiple Display Modes (2×2, 1×1, 1×2, 1×3, 2×1, 3×1 and 4×1)
- 3.5mm L/R Audio
- RS-232/Dip Switch Control
- Auto Down-Scaling
Specifications
- Video Input: 1× HDMI
- Video Outputs: 4× HDMI
- Supported HDMI Version: HDMI 1.4
- HDCP Compliance: HDCP 1.4
- Supported Resolutions:
1080p @60/50/30/25/24Hz, 720p @60/50Hz, 576p @50Hz, 480p @60Hz, 1920×1200 @60Hz, plus Various Lower Resolutions (e.g. 1680×1050, 1600×900, 1366×768, 1280×1024, 1024×768, 800×600, 640×480)
- Display Wall / Splice Modes: 1×1, 1×2, 1×3, 1×4, 2×1, 3×1, 2×2, 4×1, 1×4
- Audio Output: 3.5mm L/R Audio Output (PCM) and HDMI Audio Output (PCM)
- Control Methods: Manual via DIP Switch or Remote via RS232 (Baud Rate: 9600)
- Auto Down-Scaling: Yes
- Power Supply: DC 5V 1A
- Power Consumption: <4W
- Operating Environment:
Working Temp: –20~60°C
Storage Temp: –30~70°C
Humidity: 0–90% RH (Non-Condensing)
- Housing: Metal Casing (Black)
- Dimensions: 160 × 90 × 20.6mm
- Weight: 381g
- ESD / Surge / Lightning Protection: Yes - Supports Contact Discharge ±4kV, Air Discharge ±8kV, Compliant with IEC61000-4-2 Standard
