LENKENG 1X2 HDMI 4K@60HZ SPLITTER – 70M

Features

• 1-In and 2-Out
• Zero-Latency
• Distance up to 70m - 4K @60Hz HDR
• HDMI Loop-Out
• RS232 Control
• Bi-Directional IR Passback Function
• S/PDIF

Specifications

• Transmission Protocol: ipcolor
• Distribution Mode: 1-In, 2-Out
• Transmission Distance: CAT6/6A/7 ≤70m
• HDMI Signal: HDMI 2.0, HDCP 2.2
• HDMI Resolutions: 480i @60Hz, 480p @60Hz, 576i @50Hz, 576p @50Hz, 720p @50/60Hz, 1080i @50/60Hz, 1080p @50/60Hz, 1280x960, 1280x800, 1280x768, 1680x1050, 1360x768, 1366x768, 1600x900, 1024x768, 800x600, 3840x2160 @24/25/30/50/60Hz, 4096x2160 @24/25Hz
• Audio Formats: LPCM / DTS-HD / DTS-Audio / Dolby Digital 5.1
• IR: Bi-Directional IR Passback (20~60khz)
• RS232: 3-Pin (GND-RxD-TxD) Follows RS232 Levels
• Working Temperature: -20~60°C
• Storage Temperature: -30~70°C
• Humidity (No Condensation): 0~90% RH
• Protection: ESD Protection, 1a Contact Discharge Level 3, 1b Air Discharge Level 3, Implementation of the standard IEC61000-4-2, Lightning Protection, Surge Protection
• Power Supply: TX DC 12V 2A, RX DC 5V 2A
• Power Consumption: TX <9W, RX <4W
• Material: Aluminium-Alloy Material plus Crystal Panel
• Colour: Black
• Weight: TX 640g, RX210g
• Dimensions (L × W × H): TX 264 × 104 × 23.50mm, RX 106 × 99 × 26.2mm

Shipping Dimensions

• Weight: 1.10 kg
