UNITEK Y-3365 USB3.0 Type-C M.2 SATA SSD Aluminium Enclosure
Portable M.2 Storage Made Simple.
The UNITEK Y-3365 houses a compatible M.2 SATA SSD for use as compact external USB storage. It supports B-Key and M+B-Key SATA drives in 2230, 2242, 2260 and 2280 sizes, with a maximum supported capacity of 2TB. Its USB3.0 Type-C interface provides transfer rates of up to 5Gbps and supports UASP and TRIM for responsive performance and efficient SSD management. The aluminium-alloy housing offers a lightweight, durable design while assisting with heat dissipation. An integrated LED displays power and drive activity, and automatic sleep mode helps reduce unnecessary power consumption. Supplied with a 30cm USB Type-A to USB Type-C data cable, mounting hardware and a mini screwdriver, the enclosure provides a convenient solution for portable storage, backups and accessing compatible M.2 SATA drives.
Features
- M.2 SATA SSD Support - Accommodates compatible B-Key and M+B-Key NGFF/SATA solid-state drives
- Four Supported Drive Sizes - Compatible with 2230, 2242, 2260 and 2280 M.2 form factors
- Up to 2TB Capacity - Supports compatible M.2 SATA SSDs with capacities up to 2TB
- 5Gbps USB Connectivity - USB3.0 interface provides theoretical data-transfer rates of up to 5Gbps
- UASP and TRIM Support - Helps optimise transfer performance and maintain compatible SSD operation
- Aluminium-Alloy Housing - Provides a compact, lightweight enclosure with effective passive heat dissipation
- Automatic Sleep Mode - Reduces unnecessary power consumption during periods of inactivity
- Power and Activity Indicator - Integrated LED displays power, data activity and sleep status
Specifications
General
- Maximum Supported Capacity: 2TB
- Material: Aluminium-Alloy
- Colour: Grey
- Power Source: USB Bus-Powered
Ssd Compatibility
- Supported Drive Interface: M.2 SATA, NGFF
- Supported Key Types: B-Key and M+B-Key
- Supported Drive Sizes: 2230, 2242, 2260 and 2280
- Drive Slots: 1× M.2 SATA
- NVMe Support: No
Usb And Performance
- Enclosure Port: 1× USB Type-C Female
- USB Standard: USB3.0
- Maximum Data-Transfer Rate: Up to 5Gbps
- Included Host Cable: USB Type-A Male to USB Type-C Male
- Cable Length: 30cm
- UASP Support: Yes
- TRIM Support: Yes
System Compatibility
- Windows: Windows 10 and Windows 11, 32-Bit and 64-Bit
- macOS: Mac OS 10.6 or Later
- Linux: Linux Kernel 3.x
Physical
- Dimensions: 105 × 40 × 9mm
- LED Indicator: Power, Drive Activity and Sleep Status
- Cooling Method: Passive Aluminium Heat Dissipation
Note
- Compatible with M.2 SATA SSDs only; M.2 NVMe and PCIe SSDs are not supported
