- Input voltage: (Standard kit option): 230v AC, 50Hz-60Hz
- Primary supply to the electric motor: ACDC Power Pack with battery as back-up only (24V, 3.5Ah)
- Maximum duty cycle (work rate) with mains present: 40 cycles/hour
- Number of operations on battery reserve without AC mains power failure present: 100 within the first 24h of power failure
- Maximum gate mass: 1700kg 3m leaf
- Maximum gate leaf length: 7m 700kg mass
- Rated force: 2700N
- Rated linear running speed: 13mm/sec
- Typical operating time
Product available on special order
Manufacturer overview
For fast operation of swing gates with leaves up to 5 m or 400 kg (TO5024HS) and up to 6 m or 1450 kg (TO6024HS). Ideal for residential and industrial applications.
