Name: Gate Motor Drive 1000 + Batt (Only)
Brand: Regal
SKU: GA01
Price: 12144.00 ZAR
Availability: InStock

Roll over image to zoom in Click on image to zoom

Input voltage: 220 - 240Vac @ 50Hz - 60Hz
Primary power supply to electric motor: 288VA toroidal transformer (Power Pack)
Maximum duty cycle with 220Vac present: 98%
Motor power: 24VDC, 250W
Battery: 24Volt 5Ah
Number of operations on battery reserve without AC present: 100 within 24 hours
Battery charger: Built in multiple stage with cycling and battery health monitor
Maximum gate mass: 1000kg
Rated starting thrust: 500N
Rated running thrust: 400N
Maximum gate travel: 40m
Maximum gate speed: 28m/min
Anti-crushing safety sensing: Yes – Electronic gate profiling
Built-in receiver frequency: 433.2 MHz
Receiver memory capacity: 1000 users - 4 channels each
4 receiver channels: Button trigger, pedestrian, auxiliary relay, holiday lock-out
Tamper alarm monitoring: Safety beam tampering, gate forced open and gate kept open monitoring
Ancillary connections: Either traditional switched wiring or 2 wire daisy chained NICE BlueBus
Auxiliary power supply output: 12VDC @ 400mA, electronically protected
Auto-close modes: Simple auto-close, Condominium or Passive Infra-red Access Control (PIRAC)
Pedestrian mode: Either auto-close or 2 step logic
Operating temperature range: -10°C to 50°C (14F to 122F)
