Fanvil GA10 SIP ATA Gateway with FXS Port
Bring VoIP Calling to Your Analogue Phone.
The Fanvil GA10 SIP ATA Gateway provides a simple and cost-effective way to connect a traditional analogue telephone to a modern VoIP network. Its single RJ11 FXS port supports two SIP lines, HD voice with G.722 and Opus codecs, and advanced calling features including call hold, transfer, forwarding, call waiting and 3-way conferencing. A compact design, web-based management, voice menu configuration and automatic provisioning make the GA10 easy to deploy in homes, offices and enterprise environments.
Features
- Single FXS Port - Connect one standard analogue telephone to a SIP-based VoIP service
- 2 SIP Lines - Supports two SIP accounts for flexible voice communication
- HD Voice - G.722 and Opus codecs deliver clear wideband audio
- 3-Way Conferencing - Connect three participants in one voice call
- Advanced Call Functions - Supports call hold, waiting, forwarding, transfer, DND, hotline and voicemail notifications
- 10/100Mbps Ethernet - Provides a reliable wired connection to a router, modem or network switch
- Flexible IP Configuration - Supports IPv4, IPv6, Static IP, DHCP and PPPoE
- Secure VoIP Communication - Supports SIP over TLS and SRTP media encryption
- Easy Configuration - Manage settings through the web portal or connected telephone voice menu
- Automatic Provisioning - Supports FTP, TFTP, HTTP, HTTPS, DHCP Option 66, SIP PnP and TR-069
- Flexible Power Input - Power the device through Micro USB or the DC power input
- Compact Installation - Suitable for desktop or wall-mounted installation
Specifications
- SIP Lines: 2
- FXS Port: 1× RJ11
- Network Port: 1× RJ45 10/100Mbps Ethernet
- Micro USB Port: 1× Micro USB Power Input
- DC Port: 1× DC Power Input
- Power Input: DC5V 1A
- Wideband Codecs: G.722, Opus
- Narrowband Codecs: G.711A/U, G.726, G.729A/B, iLBC
- Audio Processing: AEC, VAD, CNG, NR, AGC, PLC and Dynamic Adaptive Jitter Buffer
- Conference Calling: 3-Way Audio Conference
- IP Modes: IPv4, IPv6, IPv4 and IPv6
- IP Configuration: Static IP, DHCP, PPPoE
- SIP Protocol: SIP2.0 Over UDP, TCP and TLS
- Media Protocols: RTP, RTCP and SRTP
- Network Features: VLAN, QoS, Firewall and STUN
- Status Indicators: Power, Network, SIP Registration and FXS Call Status
- Power Consumption: 0.84~5.71W
- Installation: Desktop Or Wall-Mounted
- Device Dimensions: 85 × 68 × 22.7mm
- Working Temperature: 0~45°C
- Working Humidity: 10~95%
- Colour: Black
Notes
- The Micro USB port supports power input only
- A compatible SIP account and wired network connection are required
- Connect the analogue telephone using a standard RJ11 telephone cable
