FANVIL A11 5W POE+ OUTDOOR SIP AUDIO INTERCOM

Fanvil A11 5W PoE+ Outdoor SIP Audio Intercom

Powerful Outdoor Communication for Harsh and Noisy Environments.

The Fanvil A11 is a rugged outdoor SIP audio intercom designed for industrial facilities, access points, public spaces and other demanding environments. Its 5W high-power speaker and turbo sound chamber deliver clear, powerful audio, while dual microphones with intelligent AEC, ANR, AGC and AVC processing help maintain natural two-way communication in noisy surroundings. A remote pickup range of up to 5m supports effective voice capture across larger areas. The stainless steel front panel and aluminium-alloy body provide IP66 weather protection and IK10 vandal resistance. With PoE+, dual SIP lines, multicast broadcasting, microSD storage, relay control, alarm inputs and line-level audio output, the A11 integrates communication, broadcasting and security functions in one compact device.

Features

• 5W High-Power Speaker - Turbo sound chamber design delivers clear and powerful audio in noisy outdoor environments
• Dual-Microphone Noise Reduction - Advanced microphone processing improves voice clarity during two-way communication
• Intelligent Audio Processing - AEC, ANR, AGC and AVC algorithms help reduce echo, background noise and volume fluctuations
• Up to 5m Voice Pickup - Captures speech from a greater distance for flexible installation in industrial and public areas
• Full-Duplex Hands-Free Audio - Enables natural two-way conversations without push-to-talk operation
• IP66 Weather Protection - Dustproof and water-resistant construction for exposed outdoor installations
• IK10 Vandal Resistance - Rugged housing helps protect the intercom against impact and deliberate damage
• Stainless Steel and Aluminium Construction - Provides corrosion resistance and durability in demanding environments
• Dual SIP Lines - Supports two independently configurable SIP accounts
• PoE+ Connectivity - Combines network data and power through a single Ethernet cable
• Programmable Call Button - Supports speed dial, intercom, multicast, IP broadcasting and other configurable functions
• Multicast and MP3 Broadcasting - Supports live announcements and stored audio playback
• microSD Card Support - Enables local audio storage, recording and preset broadcast content
• Integrated Relay Output - Supports compatible electric locks, alarms and other access-control equipment
• Dual Alarm Inputs - Connects switches, door contacts, infrared probes, vibration sensors and other input devices
• Line-Level Audio Output - Connects to an active speaker or external amplifier for expanded sound coverage
• Flexible Installation - Supports standard wall mounting or optional flush mounting with the EX611 bracket

Specifications

General

• SIP Lines: 2
• Programmable Keys: 1
• Voice Pickup Range: up to 5m
• Speaker Output: 5W
• Speakerphone: Full-Duplex Hands-Free
• Local Storage: microSD Card, up to 256GB
• Call Functions: Call, Answer, Reject, Call Waiting, Speed Dial and Auto Answer
• Broadcast Functions: Multicast, Dynamic Multicast and MP3 Broadcasting

Audio

• Wideband Codecs: G.722 and Opus
• Narrowband Codecs: G.711a/u, G.729, iLBC, G.723 and G.726
• Audio Processing: AEC, ANR, AGC and AVC
• DTMF: In-Band, RFC2833 and SIP INFO
• Microphones: Dual-Microphone Array
• Audio Output: 1× Line-Level Output
• Line-Out Impedance: 1,000Ω

Network

• Ethernet Port: 1× 10/100Mbps RJ45
• Network Modes: IPv4, IPv6 or IPv4 and IPv6
• IP Configuration: Static IP, DHCP or PPPoE
• SIP: SIP v1 and SIP v2
• SIP Transport: UDP, TCP or TLS
• Media Security: SRTP
• VPN: L2TP and OpenVPN
• Network Features: VLAN, LLDP, QoS and 802.1X
• Provisioning: HTTP, HTTPS, DHCP Option 66, SIP PnP and TR-069
• Management: Web Portal, Syslog, Configuration Import/Export and Firmware Upgrade

Interfaces

• Relay Output: 1× Short-Circuit Output
• Relay Rating: Up to 30V DC 2A or 125V AC 0.5A
• Active Switching Output: 12V DC 500mA
• Short-Circuit Inputs: 2
• Tamper Alarm Switch: 1
• Audio Output: 1× 2-Pin Terminal
• DC Input: 1× 2-Pin Terminal
• Storage Slot: 1× microSD Card Slot

Power

• PoE Standard: IEEE 802.3at PoE+, Class 4
• DC Input: 12~24V DC 2A
• PoE+ Power Consumption: 1.38~9.1W
• DC Power Consumption: 0.83~7.4W
• Power Priority: PoE Takes Priority When PoE and DC Power Are Connected Simultaneously

Physical

• Protection Rating: IP66
• Vandal Resistance: IK10
• Front Panel Material: Stainless Steel
• Housing Material: Aluminium-Alloy
• Installation: Wall-Mounted or Flush-Mounted
• Dimensions With Wall Bracket: 100.95 × 100 × 45mm
• Working Temperature: -40~70°C
• Storage Temperature: -40~80°C
• Working Humidity: 10~95%

Notes

• The A11 is an audio-only intercom and does not include a built-in camera
• The EX611 flush-mounted bracket is an optional accessory sold separately
• A compatible PoE+ switch or 12~24V DC 2A power supply is required
• The IP66 and IK10 ratings apply to the device housing
