Features
- Multi-Format Input Support - HDMI, VGA and DisplayPort inputs for maximum compatibility
- Dual HDMI Outputs - Simultaneous output to two displays with flexible routing
- 4K Video Support - Supports up to 4K @60Hz (4:4:4, 8-bit) on HDMI and DisplayPort
- Integrated Audio Amplifier - 2-channel Class-D amplifier with 20W per channel output
- Advanced Audio Processing - DSP mixing, microphone input, ducking and volume control
- Microphone Integration - 6.35mm input with optional 48V phantom power support
- Audio Matrix Mixing - Flexible audio routing between inputs and outputs
- HDMI Audio Pass-Through - Supports LPCM, Bitstream and HD Bitstream formats
- Event-Based Control - Trigger input and RS-232 for automation and system integration
- Side-by-Side Display Mode - Dual HDMI outputs can drive two displays simultaneously
- Multiple Control Options - RS232, LAN, Web GUI and front panel operation
Specifications
2× Hdmi
1× Vga
1× DisplayPort
2× Unbalanced Stereo (3.5mm)
1× Microphone (6.35mm)
2× Hdmi
1× Stereo (2× RCA)
1× Stereo (2-Pin Terminal Block)
1× RS232 (3-Pin Terminal Block)
1× Trigger (10-Pin Terminal Block)
1× Lan (Rj45)
1× USB3.0 (Type-A)
1× USB3.0 (Type-B)
1× USB3.0 (Type-A, Service)
- HDMI Compliance: HDMI 2.0
- HDCP Compliance: 2.x
- Input Signal Type: 4096 × 2160 @60Hz 8-bit YUV 4:4:4
- Output Signal Type: 4096 × 2160 @60Hz 8-bit YUV 4:4:4
- Maximum Input Resolution:
HDMI: 4096 × 2160 @60Hz
DisplayPort: 4096 × 2160 @60Hz
VGA: 1920 × 1200 @60Hz
- Maximum Output Resolution:
HDMI: 4096 × 2160 @60Hz
- Audio Output: LPCM 8-Channel, HD Bitstream
- Line-In: Max. 2Vrms, 10kΩ, Unbalanced
- Power Supply: 24V 3.75A DC
- Power Consumption: 43W (Without Amplifier)
- Chassis Material: Steel
- Colour: Black
- Dimensions (W x H x D): 231.5 × 44 × 171mm
- Weight: 1.2kg
Shipping Dimensions
- Length: 28 cm
- Width: 22 cm
- Height: 10 cm
- Weight: 1.40 kg
