Features
- Multi-Format Input Support - USB Type-C, HDMI and Mini DisplayPort connectivity
- 4K Ultra HD Support - Delivers up to 4K @60Hz (4:4:4) resolution
- Automatic Signal Switching - Auto-detects and switches to the last active input
- Manual Input Control - Simple front panel button selection
- EDID Management - Optimised EDID handling for stable compatibility
- LED Status Indicators - Clear visual indication of active input and operation
Specifications
1× USB Type-C
1× Mini DisplayPort
1× Hdmi
- Output Port: 1× HDMI
- Service Port: 1× Mini USB
- HDMI Compliance: HDMI 2.0, DisplayPort 1.4, DVI 1.0
- HDCP Compliance: 2.x
- Input Signal Type: 4096 × 2160 @60Hz YUV 4:4:4
- Output Signal Type: 4096 × 2160 @60Hz YUV 4:4:4
- Maximum Input Resolution:
HDMI: 4096 × 2160 @60Hz
Mini DisplayPort: 4096 × 2160 @60Hz
USB Type-C: 4096 × 2160 @60Hz
- Maximum Output Resolution:
HDMI: 4096 × 2160 @60Hz
- Audio Input: LPCM (8 Channels), Bitstream, HD Bitstream
- Audio Output: LPCM (8 Channels), Bitstream, HD Bitstream
- Power Supply: 5V 1.2A (Mini USB)
- Power Consumption: 4.7W
- Material: Plastic
- Colour: White
- Dimensions (W × H × D): 85 × 26 × 85mm
- Weight: 80g
- Firmware Update: Mini USB
Shipping Dimensions
- Length: 12 cm
- Width: 12 cm
- Height: 5 cm
- Weight: 0.20 kg
